Home > Health & Medicine > Medical Equipment > Disinfect Equipment & Sterilizer > SG Series Ventilate Super Water Autoclave Sterilizer for Soft Infusion Bag

SG Series Ventilate Super Water Autoclave Sterilizer for Soft Infusion Bag

US$ 18,000 - 400,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Type:

Boiling Sterilization Apparatus

Brand Name:

Model Number:

SG Series

Contact Supplier Request Quote Chat Now

Huizhou Pingfang Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Boiling Sterilization Apparatus

Brand Name PF

Model Number SG Series

Place of Origin Zhejiang, China

SG Series Ventilate Super Water Autoclave Sterilizer

for soft infusion bag

This series adopts cyclical water as sterukuzation heating heating carrier and carrier and carry and carry out water-pouring sterilizing operation for articals.
During the whole working course,superherheated water operates in a relatively sealing cyclical system,which has series of advanyages,high heat efficiency,good temperature evenness,stable temperature adjusting range,etc.Besides,this equipment also effectively,good temperature evenness.stable temperature adjusting range,etc. Besides,this equipment also effectively prevents second pollution during working with anti-pressure protection device.lt can be applied widely to high-and-low temperature sterilizing operation on liquid in glass bottles.Ampoule bottles,plastic bottles, plastic packs,etc,in pharmaceutics.it is also suitable for foodstuff industery to sterilize all kinds of sealing package,drinks,cans.

Main Parameters & Utilities

Design pressure	0.245Mpa	Soft Water Pressure	0.1-0.2Mpa
Working Pressure	0.22Mpa	Steam Source Pressure	0.4-0.6Mpa
Design Temperature	139℃	Water Source Pressure	0.1-0.3Mpa
Working Temperature	134℃	Compressed Air Pressure	0.5-0.7Mpa
Heat Equilibrium	≤±1℃

Structure&Capability&Characteristics

·The box is designed, produced and tested strictly according to the "Steel Pressure Vessel"
·Pneumatic translational door,easy to operate,flexible
·Elegant stainless steel decorate cover
·The GMP confirrmation access is fixed on the equipment
·The unique dove-tail inlaid desigan of heat-resisting silicone rubber gasket ring ensures the seal tightness of the door.
·The main control system adopts micro-computer PLC+touch screen +DCS long distance tiring-room monitoring system
·The heat preservation layer is made by polyurethane matirial and pearl rock wool
·Excellent PID temperature controlling technology,accurate pressure tracking on real-time
·In order to reduce the working load, the automatic in-out system can be fixed according to the customer’s needs.

Size&Utilities

Specifications Model	Overall Dimensions LMH(mm) Single/Double Door	Chamber Size LWH(mm)	Sream Consumpyion (kg/cycle)	Power (KW)	Soft Water (kg/cycle)	Compressed Air (m/cycle)	Car	Cooling Water consumpation	Net Weight (kg)
SG-1.2	182025002000	15007501100	80	5	100	2.0	2	2000	2150
SG-2.5	332025002000	30007501100	130	5	200	4.0	4	4000	3100
SG-5	378031502250	340010001500	250	8	450	10.0	4	8500	5500
SG-13	458040002820	Ø2000*4200	580	15	1000	25.0	4	9000	8500
SG-26	858040002820	Ø2000*8200	1200	20	1500	45.0	8	16000	10500
SG-32	1058040002820	Ø2000*10200	1400	30	2000	45.0	10	20000	15000
SG-40	874052003220	Ø2500*8360	1800	30	2500	55.0	16	24000	18500
SG-62	1282052003220	Ø2500*12440	2800	60	4000	90.0	24	40000	31000

Note:The overall dimensions,chamber size,and the quantity of sterilizing car are for glass bottle.And there is a bit difference for soft bag.

Load Model	?Glass bottle			Plastic bottle			?Fot soft bag
Load Model	100ml	250ml	500ml	100ml	250ml	500ml	100ml	250ml	500ml
SG-1.2	2016	990	544	1400	768	480	520	416	312
SG-2.5	4032	1980	1088	2800	1536	960	1040	832	624
SG-5	7868	3960	2160	5568	3260	2112	2160	1800	1400
SG-13	14400	7840	4536	10584	6120	4200	4320	3600	2160
SG-26	28800	15680	9072	21168	12240	8400	8640	7200	4320
SG-32	36000	19600	11340	26460	15300	10500	10800	9000	5400
SG-40	44800	24192	13248	32928	19584	12000	13440	11200	8960
SG-62	86400	47040	27216	63504	36720	25200	20160	16800	13440
