FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen

FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen photo-1
FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen photo-2
FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen photo-3
FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen photo-4
FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen photo-5
FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen photo-6
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Crusher
Product Type:
Other, foodstuff, chemical, pharmaceutical
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port China(Mainland)
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Crusher
Product Type Other, foodstuff, chemical, pharmaceutical
Place of Origin Jiangsu, China
Brand Name PF
Model Number FYF Series Crusher Machine
Voltage 380V
Power(W) 0.37/1.5kw
Dimension(L*W*H) 350*290*750mm/460*450*1080mm
Weight 25/40kg, 25/40kg
Certification GMP
Warranty 1 Year, One year
After-sales Service Provided Engineers available to service machinery overseas

FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen

Product Description

Main Application

    The machine is fruits and vegetables food processing machine which is used for restaurants, canteen of large-scale enterprises and Food factory. The machine is to grind fresh fruits and vegetables into mashed and particle form, such as garlic, ginger, vegetables, fresh chili and fruits.


Working principle

    The machine is made up of material barrel, crushing knives, sealing parts, frame, and motor and driving shaft. The motor is in the frame box and the lower of driving shaft is directly installed on the shaft of motor, the driving shaft stretch into the material barrel and there are two pieces of blades on the top of the shaft. The blades are installed as X form so there would be no dead angel and improve the working efficiency. The blades are made of good quality stainless steel and heated; the blades are sharp, very hard and can use long time. The sealing parts between driving shaft and material barrel are made of silicon which are without noxious and pollution, good sealing and no leak.When working, put the clean raw materials into barrel and feed moderate water, starts the motor and let the blades rotary high speed, the raw materials will be particle form and will be mashed if still working. After working, you can open the top cover and let the barrel tilt, pour the materials and clean the barrel by water.

Technical parameters



Model Volume of barrel Feeding volume  Motor Power Spindle Speed overall dimension weight
FYF-10 10L 5L 0.37kw 2800r/min 350*290*750mm 25kg
FYF-30 30L 15L 1.5kw 2800r/min 460*450*1080mm 40kg



Machine Show

         FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen

FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen

Samples

 FYF Series Fruit and Vegetable Crusher Machine for Restaurants and CanteenFYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen



Packaging& Shipping

 FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen

FAQ

 FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen

Company Information

 FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen

FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen

FYF Series Fruit and Vegetable Crusher Machine for Restaurants and Canteen
