GF Series Dust Absorption Pulverizer Machine for Grain and Wheat
Main Application
This set is applied for such trades as pharmaceutical, foodstuff, chemical and so on. which is specially used for crush for crushing materials with much fiber or grease.
Working principle
This machine is made up of crusher, cyclone separator, pulse dust-collecting box etc., Material come into the chamber through the hopper, and crushed by high speed rotating hammers, crushed size can be adjust by screen. The crushed material flows into the cyclone separator by the induced fan and rotating centrifugal force, then being discharged through gate blower,dust come into the pulse dust-collecting box, filtrated and recycled by the filter cylinder. Designed by the standard of GMP, the whole machine is made of stainless steel, and there is no dust during the process of production.
| Model | Production Capacity | Feeding Size | Crushing Fineness | Crushing motor | Dust collecting motor | Discharge motor | overall dimension | weight |
|---|---|---|---|---|---|---|---|---|
| GF-250 | 50-150kg/h | ≤6mm | 60-200mesh | 5.5kw | 2.2kw | 0.75kw | 3000*880*2150mm | 550kg |
| GF-350 | 80-500kg/h | ≤6mm | 60-200mesh | 11kw | 4kw | 0.75kw | 3500*880*2150mm | 880kg |
| GF-450 | 100-600kg/h | ≤10mm | 60-200mesh | 22kw | 5.5kw | 0.75kw | 4500*880*2250mm | 1500kg |
| GF-650 | 150-1200kg/h | ≤12mm | 60-200mesh | 37kw | 11kw | 1.5kw | 6580*1100*2380mm | 2000kg |
| GF-850 | 200-2000kg/h | ≤15mm | 60-200mesh | 55kw | 15kw | 1.5kw | 7800*1100*2380mm | 2800kg |
