YSZ Series Hydraulic construction hoist lifting machine price
I. Itroduction:
YSZ series hydraulic hoist and particle machine can turn the materials in the boiling particle machine and material trolley directly into needed particles for entry into general mixing drum. It has the outstanding characteristics of low noise, easy washing and easy granularity control, it also connects the three pharmaceutical processes closely: boiling forming particles, particle alignment and general mixing, thus optimizing technological process, effectively preventing flying dust and cross contamination, reducing labor intensity, and raising working efficiency. It is an ideal machine for pharmaceutical plants to realize enclosed production.
II. Features:
1.This machine is made of SUS304 stainless steel. All the parts in contact with the materials art polished, with a surface roughness of Rao 2. The filling arm groove, treated for curtain type separation, has a fine appearance.
2.This machine adopts a combination of electrical and hydraulic control, and ensures a steady and reliable performance. Equipped with a rocker operating system, it is easily and flexibly operated. It can be looked automatic all at any height so as to meet different requirements in the production.
3.This machine has an oil reservoir using imported sealings so that clean areas are not polluted due to hydraulic leakage.
4.The hydraulic loop of the machine has an automatic pressure hold function, so that even in case of power breakdown, the lifting arm can still stay at its original position.
5.In case of pressure drop due to hydraulic leakage with this machine, there will an automatic alarm. The machine will automatically start pressure increase and maintain the position of the lifting arm without damaging other equipment, thus ensuring safety in production.
6.The conical cover of the machine is ready-made to suit the need for the material trolley of the boiling particle machine and is equipped with a sealing device so that there is no dust flying during tumbling of the material drum. Special outlet butterfly valves, which have no dead angle and are easily detachable and washable, make it easy for the materials to be discharged.
7.The main shaft of the particle alignment knife is speed regulated through frequency variation, and the clearance between the knife and the screen net is adjustable to meet the requirements of different products.
8.The particle machine is installed on the column of the hoist to integrate the hoist and the particle machine, enable easy operation and save space.
III. Technical Parameters:
Model | YSZ-120 | YSZ-150 | YSZ-200 | YSZ-300 |
General power (Kw) | 5.2 | 6.0 | ||
Hydraulic motor power (Kw) | 2.2 | 6.0 | ||
Lifting weight (Kw) | 120 | 150 | 200 | 300 |
Lifting speed (mm/min) | 1500 | |||
Turning angle (°) | 0-180 | |||
Height (mm) | Depending on the general mixing drum and boiling frolley used | |||
Depth (mm) | 2340 | 2430 | 2540 | 2740 |
Diameter(mm) | 1200 | 1290 | 1400 | 1600 |
Whole-pill motor power (kw) | 3.0 | |||
Whole-pill productivity (kg/h) | 100-1000 | |||
While-pill speed regulating range(rpm) | 125-1250 | |||
Packaging Details: Export-standard and sea-worthy wooden case as following photos.
Delivery time: 15-45 working days normally
Free service: normal spare parts and quick worn parts will be delivered together with the main machine.
Huizhou Pingfang pharmaceutical machinery co. ltd. is a professional manufacturer and supplier for pharmaceutical machinery, pharmaceutical packing material company, who is standing firmly with a good reputation in the industry of China pharmaceutical machinery.
Our company focus on fabricating efficient and technically sound pharmaceutical machines that meets or exceed our customer’ expectations. Our vast product selection caters to numerous industries, worldwide. We are specializing in machinery including, pulverizes, mix, Granulate, tablet press machine, coating machine, soft capsules filling machine, hard capsules filling machine, ampoule filling and sealing machine, oral liquid filling production line, syrup machine, eyes drop filling machine, lyophilized powder production line, injectable vial powder filling production line, Ointment machine, Suppository machine, spray filling machine, pharmaceutical testing and experiment instrument, traditional Chinese medicine machine and packing materials. The packing materials including pharmaceutical PVC, PTP aluminum film, hard aluminum, vial, stopper, aluminum stopper, ampoule, glass, capsule, packing strap of suppository physic. Meanwhile, we can undertake turn key projects for conceptual design, process design, water treatment solutions, clean-room design, etc.
Because we stick to offer the high quality and competitive price to our customer, our machines have been exported many countries of world such as Singapore, Vietnam, Malaysia, Thailand , Bangladesh, USA, Russia, Pakistan, Nigeria, Chile, Germany, Denmark, Bolivia, Peru, Mexico, South Africa, Iran, Argentina, Canada, Australia, India, Kazakhstan, Turkey, Egypt, Brazil, Syria, Yemen and more. In order to offer the best quality, we manufacture our products in accordance with international standards, such as FDA, GMP, CGMP. We also be approved by CE, ISO certificate, too.
We have established business relationship with many directly customers and have many agencies from abroad.
Customer service including technical support, installation & commissioning after sale.
Welcome all of friends from abroad to our company and establishing good business cooperation.
Our Customers:
Our Certificates:
Q1: What should I do to choose the best machine for us?
A: Tell me the size and shape of the tablet you need to press, and the capacity of the machine you need. We will suggest you the most suitable and economical one.
Q2: Does molds customized accepted,
A: Yes. Please send us your mould design, and the diameter you need, then we'll offer you the best price according to your requirement.
Q3: Do you have manual or operation video for us to know more about the machine?
A: Yes. We'll send you the manual and operation video after you asking from us.
Q4: When can I get the price?
A: We usually quote within 24 hours after getting your inquiry. If you are urgent to get the price, please call us or tell us in your email. We will regard your inquiry priority.
Q5: How does your factory regard quality control?
A: Quality is priority. We always attach great importance to quality control from raw material to the very end.
Pre-sale:
According to customer’s needs guide customers t configure the most appropriate device models. According to customer’s special requirements and working site provide list of equipment, equipment layout.
Dur-sale:
Inspect the product seriously before out of the factory. Invite customer for commissioning in the spot and raising the objection. Organize to delivery according to the contract.
After-sale:
Company can send technical data for guiding to install and debug the machine. After a year, we can instruct you how to maintain the machine, and spare parts are provided with the best price. We also can provide 24-hour telephone or message service.
