(H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE

(H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Drying Oven
Place of Origin:
Zhejiang, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port China(Mainland)
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Drying Oven
Place of Origin Zhejiang, China
Brand Name PF
Model Number GMS
Voltage 220v/380v
Power(W) 50kw
Dimension(L*W*H) 4500*1630*1900 (mm)
Certification CE ISO
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

(H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE



Product Description



1. Introduction:

H-gms-a series tunnel oven is a tunnel type laminar flow oven designed by our company after massive market researching and referring the similar product home and abroad.This oven can reach the standard of sterilization and removing pyrogen after many years of pharmaceutical factory usage and test before leaving the factory.





2. Working principle:

This machine consists of pre-heating section, sterilization section, cooling section, net conveyor and electric control system.

It use electric heating to sterilize and remove pyrogen of the bottles after washing under the temperature of 350℃.The whole process is finished under 100 class degree protection.


3. Technical diameters:




Suitable bottle range

1~20ml,2~500ml(ampoule, tubular or molded vial)


Sterilization temperature

350℃


Sterilization time

≥ 5min~7min


Net conveyor speed

50~250mm/min


Bottle outlet temperature ambient temp

 +15℃


Lean degree

100(class)


Cooling type: air cooling




Fan


ydf type low noise fan 2 units


Power supply

380V 50Hz


Electric heater


quartz glass heater or s.S. Heater


Single machine noise

≤70dB


Dimension: (l×w×h)

GMS-500: 4500×1630×1900 (mm)

GMS-700: 6000×1820×1900 (mm)

GMS-900: 8000×2020×1900 (mm)


Power

GMS-500: 50kw
GMS-700: 72kw
GMS-900: 90kw












other machines



 (H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE(H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE



product samples

 (H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE(H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE





Packaging & Shipping



Packaging Details: Export-standard and sea-worthy wooden case as following photos.

Delivery time: 15-45 working days normally

Free service: normal spare parts and quick worn parts will be delivered together with the main machine.



(H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE  (H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE



Company Information

Huizhou Pingfang pharmaceutical machinery co. ltd. is a professional manufacturer and supplier for pharmaceutical machinery, pharmaceutical packing material company, who is standing firmly with a good reputation in the industry of China pharmaceutical machinery.

Our company focus on fabricating efficient and technically sound pharmaceutical machines that meets or exceed our customer’ expectations. Our vast product selection caters to numerous industries, worldwide. We are specializing in machinery including, pulverizes, mix, Granulate, tablet press machine, coating machine, soft capsules filling machine, hard capsules filling machine, ampoule filling and sealing machine, oral liquid filling production line, syrup machine, eyes drop filling machine, lyophilized powder production line, injectable vial powder filling production line, Ointment machine, Suppository machine, spray filling machine, pharmaceutical testing and experiment instrument, traditional Chinese medicine machine and packing materials. The packing materials including pharmaceutical PVC, PTP aluminum film, hard aluminum, vial, stopper, aluminum stopper, ampoule, glass, capsule, packing strap of suppository physic. Meanwhile, we can undertake turn key projects for conceptual design, process design, water treatment solutions, clean-room design, etc.

Because we stick to offer the high quality and competitive price to our customer, our machines have been exported many countries of world such as Singapore, Vietnam, Malaysia, Thailand , Bangladesh, USA, Russia, Pakistan, Nigeria, Chile, Germany, Denmark, Bolivia, Peru, Mexico, South Africa, Iran, Argentina, Canada, Australia, India, Kazakhstan, Turkey, Egypt, Brazil, Syria, Yemen and more. In order to offer the best quality, we manufacture our products in accordance with international standards, such as FDA, GMP, CGMP. We also be approved by CE, ISO certificate, too.



Our Customers:

(H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE



(H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE



Our Certificates:

(H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE(H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE(H-GMS-A) GMS SERIES STERILIZING TUNNEL OVEN FOR SALE



FAQ

Q1: What information should I let you know if I want to get quotation?

A: -the size of products (Length*Width*Height)

   -the material

   -if it is possible, please provide us the pictures or the design drawings, our designer will analyze your samples and give you exact details.



Q2: Is there MOQ for our machine?

A: 1 set is acceptable. Of course, if you order more, it will be fine and its price will be more competitive.



Q3: Do you have manual or operation video for us to know more about the machine?

A: Yes, of course. Please email us and ask for it. We will send you soon.



Q4: When can I get the price?

A: We usually quote within 24 hours after getting your inquiry. If you are urgent to get the price, please call us or tell us in your email. We will regard your inquiry priority.



Q5: How does your factory regard quality control?

A: Quality is priority. It’s the basement of company’s development. From the beginning of opening company, we especially focus on quality job. Our pharmaceutical equipment have passed the GMP model patents and invention patents issued by State Patent Office of China.



Our Services



Pre-sale:

According to customers needs guide customers t configure the most appropriate device models. According to customers special requirements and working site provide list of equipment, equipment layout.

Dur-sale:

Inspect the product seriously before out of the factory. Invite customer for commissioning in the spot and raising the objection. Organize to delivery according to the contract.

After-sale:

Company can send technical data for guiding to install and debug the machine. After a year, we can instruct you how to maintain the machine, and spare parts are provided with the best price. We also can provide 24-hour telephone or message service.
