Product Details
Place of Origin: | Shanghai, China | Brand Name: | PF | Model Number: | ZW-80B |
Application: | Other, Granules, herb extraction machine | Type: | Granulator | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
ZW-80B and ZW-20B type standing-style auto-making the traditional Chinese medicine pill machine
I. Introduction:
ZW-20B type standing-style auto-making the traditional Chinese medicine pill machine,is the main producing pill equipment not only in domestic or but abroad at present (referring to the traditional Chinese medicine small pill specially), it can produce honey pillwater pill water-honey pill concintration pill paste pill etc. These serial products are served to big middle small scale pharmaceutical factory and agent department of Chinese medicine hospital.
Drug material mixed equally is thrown into wimble-model material drainage, the machine will thrust out many identical diameter drug sticks by squeezing of the helix of propelle. Under the control of self-control lidler pulley, the drug sticks enter into making pill knife in-phase, big and small equal pills will be twisted continuously.
II. Features:
1,stable behavior, simple operation, convenient maintenance. The parts of contacting drug are all stainless steel material, it accords with GMP standard.
2,circular of the shape of pill,equal dimension size, making shape one time, without screening.
3,coming out strips equally, good multi-strip synchronism, collapsing degree is coincident with stipulation of pharmacopeia.
4,high automatization degree, good enclosure, decreasing chance of drug catching bacteria.
III. Technical diameters:
Model | Capacity kg/h | Specifications(mm) | Scope | Power (kW) | Size(mm) (L×W×H) | Weight (kg) |
ZW-80 | 60-80 | (unit as diameter of pill) 2~12,as well as other non-integerdiameters of pills and large pills of 3,6,9gram | Bolus, watertight pill, enriched pill and waterpill | 3 | 1050×700× 2100 | 600 |
ZW-20 | 20-40 | 1.75 | 900×700× 1200 | 300 |
Packaging Details: Export-standard and sea-worthy wooden case as following photos.
Delivery time: 15-45 working days normally
Free service: normal spare parts and quick worn parts will be delivered together with the main machine.
Huizhou Pingfang pharmaceutical machinery co. ltd. is a professional manufacturer and supplier for pharmaceutical machinery, pharmaceutical packing material company, who is standing firmly with a good reputation in the industry of China pharmaceutical machinery.
Our company focus on fabricating efficient and technically sound pharmaceutical machines that meets or exceed our customer’ expectations. Our vast product selection caters to numerous industries, worldwide. We are specializing in machinery including, pulverizes, mix, Granulate, tablet press machine, coating machine, soft capsules filling machine, hard capsules filling machine, ampoule filling and sealing machine, oral liquid filling production line, syrup machine, eyes drop filling machine, lyophilized powder production line, injectable vial powder filling production line, Ointment machine, Suppository machine, spray filling machine, pharmaceutical testing and experiment instrument, traditional Chinese medicine machine and packing materials. The packing materials including pharmaceutical PVC, PTP aluminum film, hard aluminum, vial, stopper, aluminum stopper, ampoule, glass, capsule, packing strap of suppository physic. Meanwhile, we can undertake turn key projects for conceptual design, process design, water treatment solutions, clean-room design, etc.
Because we stick to offer the high quality and competitive price to our customer, our machines have been exported many countries of world such as Singapore, Vietnam, Malaysia, Thailand , Bangladesh, USA, Russia, Pakistan, Nigeria, Chile, Germany, Denmark, Bolivia, Peru, Mexico, South Africa, Iran, Argentina, Canada, Australia, India, Kazakhstan, Turkey, Egypt, Brazil, Syria, Yemen and more. In order to offer the best quality, we manufacture our products in accordance with international standards, such as FDA, GMP, CGMP. We also be approved by CE, ISO certificate, too.
Our Customers:
Our Certificates:
Q1: What information should I let you know if I want to get quotation?
A: -the size of products (Length*Width*Height)
-the material
-if it is possible, please provide us the pictures or the design drawings, our designer will analyze your samples and give you exact details.
Q2: Is there MOQ for our machine?
A: 1 set is acceptable. Of course, if you order more, it will be fine and its price will be more competitive.
Q3: Do you have manual or operation video for us to know more about the machine?
A: Yes, of course. Please email us and ask for it. We will send you soon.
Q4: When can I get the price?
A: We usually quote within 24 hours after getting your inquiry. If you are urgent to get the price, please call us or tell us in your email. We will regard your inquiry priority.
Q5: How does your factory regard quality control?
A: Quality is priority. It’s the basement of company’s development. From the beginning of opening company, we especially focus on quality job. Our pharmaceutical equipment have passed the GMP model patents and invention patents issued by State Patent Office of China.
Pre-sale:
According to customer’s needs guide customers t configure the most appropriate device models. According to customer’s special requirements and working site provide list of equipment, equipment layout.
Dur-sale:
Inspect the product seriously before out of the factory. Invite customer for commissioning in the spot and raising the objection. Organize to delivery according to the contract.
After-sale:
Company can send technical data for guiding to install and debug the machine. After a year, we can instruct you how to maintain the machine, and spare parts are provided with the best price. We also can provide 24-hour telephone or message service.
