DW-SW600 Microplate Washer
Main Features:
- Touch LCD Screen, easy operation
- Aspirate and dispense needle are separated
- Three channels: detergent channel, rinse channel and wash channel
- Three kinds of different plates can be washed(include flat bottom, U bottom and V bottom)
- Dispense, aspirate, and soak can be programmed at user’s disposal.
- Several wash method can be chose(regular mode,2 point mode and bottom clean mode)
- Plate shaking function and the intensity can be adjustable
- Automatic calibrate the manifold and also fine tuning
- Automatic monitoring pressure and vacuum, automatic rising cycle
- Liquid waring
- Emergency stop available can be continued
- Large memory to store up to 99 user programmed wash protocols.
Main Specifications
Manifold | 8 Pins and 12 Pins |
Wash mode | Strip Mode and Plate Mode |
Strips | 1-12 (according to manifold) |
Wash Volume | 50-9999uL(1uL increase) |
Wash times | 1-99 times |
Soak time | 0-99 minutes 99 seconds |
Bottle volume | 2L (Distill Water bottle, Detergent A bottle, B bottle, Waste bottle) |
Wash method | 99 kinds |
Plate type setting | 10 kinds |
Residual Volume | ≤2ul |
Distribution accuracy | ≤5% |
Imbibition s pump negative pressure | 30 Kpa |
Liquid exhaust | Detergent:50ml/plate Prewashing:20ml |
Display | 240X128 Dot matrix LCD (Touch screen) |
Dimension(Instrument) | 330*380*208mm |
Input power | 120VA |
Power supply | AC 110-240V, 50Hz/30Hz |
Working temperature | 10℃—30℃ |
Room relative humidity | Less than 85% |
Weight | 9.6Kg |
Storage conditions | Under the condition of outer packing Storage conditions: 40℃—55℃ Storage humidity less |
Language | Standard English or Multi-language software available on request. |
Pictrues for real products
