DW-SW800 Large LCD Display Microplate Washer With Touch Screen

Name: DW-SW800 Large LCD Display Microplate Washer With Touch Screen
Brand: DRAWELL
SKU: 141124258
Availability: InStock

Shanghai Drawell Scientific Instrument Co., Ltd.

US$ 900 - 2,950 MOQ: 1 Piece

Key Specifications

Brand Name:

DRAWELL

Model Number:

DW-SW800

Place of Origin:

Shanghai, China

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Brand Name DRAWELL

Model Number DW-SW800

Place of Origin Shanghai, China

DW-SW800 Microplate Washer

Features

Large LCD display, microcomputer control, touch screen.
8-way or 12- way manifolds is available according to your conditions, wash head types: microplate 12 line×8 well and 8 line×12 well are available.
Washes flat, U and V-bottom strips and plates.
Metal bottom holder, corrosion protection, stable plate washer.
Plate shaking and soaking function, time adjustable.Liquid level detection and alert function.
Bottom clean and multipoint liquid absorption function, on average every plate each hole residual volume: <0.8μl /well
High precision volume dispensing, dispense uniformity: CV < 2%
Manifold with two needles for aspiration and dispensation, avoid cross-contamination.
Uniform dispensing, low residual volume.
User-friendly operation system.
Standard English or Multi-language software available on request.

Main Specifications

Manifold	8 Pins and 12 Pins
Wash mode	Strip Mode and Plate Mode
Strips	1-12 (according to manifold)
Dispense Volume	0-9999uL
Dispense Volume range	50~999μl
Wash times	1-99
Soak time	0-99 minutes 99 seconds
Bottle volume	2L (Distill Water bottle, Detergent A bottle, B bottle, Waste bottle)
Wash method	99 kinds
Plate type setting	10 kinds
Residual Volume	≤0.8ul
Dispense repeatability	≤2%
Imbibitions pump negative pressure	0.5 Bar
Liquid exhaust	Detergent:50ml/plate Prewashing:20ml
Display	240X128 Dot matrix LCD (Touch screen)
Dimension(Instrument)	480x330x140mm
Input power	150VA
Power supply	AC 220V, 50Hz
Working temperature	10℃—30℃
Room relative humidity	Less than 85%
Weight	7.8Kg
Storage conditions	Under the condition of outer packing Storage conditions: 40℃—55℃ Storage humidity less
Language	Standard English or Multi-language software available on request.
