DW-PH6810 PH/ORP/Temp Portable Meter VisionPlus Digital Ph/ORP Meter

Name: DW-PH6810 PH/ORP/Temp Portable Meter VisionPlus Digital Ph/ORP Meter
Brand: DRAWELL
SKU: 141124116
Availability: InStock

Shanghai Drawell Scientific Instrument Co., Ltd.

US$ 94 - 336 MOQ: 1 Piece

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

DRAWELL

Model Number:

DW-PH6810

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name DRAWELL

Model Number DW-PH6810

Product Description

pH/ORP/Temp Portable Meter VisionPlus DW-PH6810

Features

Simultaneous display of pH or ORP and temperature measurements.

Automatic temperature compensated (ATC) pH readings.

1, 2 or 3 point pH calibration, electrode efficiency display.

End point sensing and hold.

Dual buffer set selection: (4.01, 7.00, 10.01) or (4.00, 6.86, 9.18).

Automatic or manual temperature compensation.

Low battery indicator.

IP67 waterproof housing.

Rugged rubber shockproof protective boot provides extra protection in the field.

RoHS compliant.

Specifications
Range	pH	-2.00~16.00pH
	ORP	-1999~+1999mV
	Temperature	-10.0~120.0℃
Resolution	pH	0.01pH
	ORP	1mV
	Temperature	0.1℃
Accuracy	pH	±0.1%FS±2 digits
	ORP	±0.1%FS±2digits
	Temperature	±0.3℃±1 digits
pH Electrode Offset Recognition		±90mV
pH Electrode Slope Recognition		±30%
Electrode Input Impedance		>10¹²Ω
Electrode Type		3-in-1 pH / Reference / Temperature electrode
ATC		Thermistor, 10KΩ at 25℃
Calibration Backup		Yes
Temperature Compensation		Automatic or Manual
Display		Large LCD
Power		4 X 1.5 Volt AAA batteries
Auto Power Off		After 20 minutes of inactivity
Battery Life		>1000 hours
Ambient Temperature Range		From 0~50℃
Case		IP-67 waterproof with rubber shockproof protective boot.
Weight / Dimensions ( W x D x H )		230 grams (Including batteries) / 75cm x 157cm x 35cm
Accessories
6810P		pH / Temperature / Reference electrode with BNC and Mini 8 DIN connector
