electrical crimp terminal machines BJ-3000F
Technical parameters:
Type | Automatic computer single head terminal crimping machine BJ-3000F |
Power | AC220V 50 / 60HZ ( single phase ) |
Function | Wire cutting, both side stripping, single side stripping, |
Capacity | 4500 strip/h (within 300mm length) |
Speed | >5000pcs/hours |
Wire Processing range | AWG # 30 - AWG # 20 |
Wire Length | 35mm-8m |
Cutting length | 28mm-9999mm. Replacing some parts can cut to 25mm(shortest) |
Cutting fine | Change range:1mm+ below cutting length 0.1%) |
stripping length | 0.1mm-10mm |
Air pressure | 0.5Mpa(5kgf/cm) About 200NL/Min |
Detection device | It will alarm downtime when appears lack of abnormal, |
Pressure capacity | 19600N(2T) |
Twisting length | AWG # 20-AWG # 30 (4mm-8mm) |
Machine size | 80 * 80 * 170(mm) |
Machine weight | About 130kg |
Feature
A. This machine is composed by Mitsubishi controller from Japan, high precision, stable performance.
B. Using 256 colors color touch curtain, full Chinese menu, PLC control.
C. Terminal crimping use Japanese motor mute terminal machine. No noise, low fault..
D. Equipment is mainly made of original imported parts, complete severing the wire, stripping, terminal crimping dynamic is precision, simple operation, stable performance.
E. Wire pressing roller tightness adjustable, cutter depth adopt spinner rotation adjustment, simple and quick.
F. Full stripping length directly set by the touch curtain Chinese menu panel setting. The best characteristics: Technology operation performance adjustment fast, short adjusting time, simple operation.
We Provide
- Best products and factory price.
- On-time delivery and the shortest delivery time.
- 1-year warranty. If our products cannot function properly within 12 months, we'll offer spare parts for free; and you need to pay for the delivery.
- OEM and customized service.
- User manuals will go with relative machines.
Service
- QC: All products will be checked before delivery.
- Compensation: If any unqualified product is found, we'll pay the compensation or send new qualified products to customers.
- Maintenance & Repair: In case of any maintenance or repair need, we'll help to find out the problem and offer relative guidance.
- Operation Guidance: If you have any problem with operation, please feel free to contact us.
...
