BJ-2000FT Fully Automactic Single Head Twisting Machine And Tinning Machine

BJ-2000FT Fully Automactic Single Head Twisting Machine And Tinning Machine photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
BOJIN
Model Number:
BJ-2000FT
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name BOJIN
Model Number BJ-2000FT
Usage Crimping

BJ-2000FT Fully Automactic Single Head Twisting Machine And Tinning Machine



Product Description

Fully automactic Single head wire cutting, stripping, twisting, tinning machine BJ-2000FT
1.Automaitc electric wire cutting, stripping and tinnning processing machine, both end tin machine
2.Automatic electric wire cutting stripping tinning processing machine

Machine features:

1, ultra-compact design, small footprint, computer touch-sc reen Chinese menu operation, easy to use;
2, The replacement process and the material very rapidly, high efficiency, high precision, speed, easy maintenance;
3, The machine uses servo control: 5 sets of servo (Delta servo Mitsubishi servo);
4, Pneumatic components: electromagnetic raft + cylinder (SMC), air pressure detecting SMC;
5, Screw rails: TPI / THK;
6, Color touch sc reen: Step Section (Taiwan);
7, The entire computer numerical control debugging: blade size, cutting wire length, strip length, twisting strength speed,
flux dip depth, the depth of wetting, are to achieve digital touch sc reen operation;

* Dimesions:1200*1200*720
* Weight:500kg
* Display:LCD display English language touch sc reen
* Power:AC220/50Hz
* Fuction:Wire cutting, stripping a single-ended, double-ended stripping, single-head crimping, twisting single-ended line, single-ended tinning
* Wire size:AWG32#-AWG16#
* Speed:5500/h AWG32#-16#
* Cutting length:Max length 450mm
* Stripping length:0.1mm-10mm
* Tinning length:1mm-10mm (Changable)
* Twisting length:2mm-10mm (Changable)
* Available wire:Electronic wire, high temperature wire, etc.
* Twisting way:Digital Operation (motor drive mode)
* Detective function:Lack of wire, wire tie, pressure checking
* Air pressure:More than 6kg

BJ-2000FT Fully Automactic Single Head Twisting Machine And Tinning MachineBJ-2000FT Fully Automactic Single Head Twisting Machine And Tinning MachineBJ-2000FT Fully Automactic Single Head Twisting Machine And Tinning MachineBJ-2000FT Fully Automactic Single Head Twisting Machine And Tinning Machine





Operation Video



Payment & Delivery

* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.

We Provide

* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.

Service

* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us.
