Eletrical Type Terminal Crimping Machine BJ-601E
- Crimping range: 0.5-16mm2
- Output:2.5T
- Voltage range: AC 220V
- Weight: 10kg
- Overall dimension: 140*220*320mm
Benefits:
Automates your hand tools
Eliminates operator hand faigue-foot pedal controls the unit
Low cost alternative to automatic crimping machines
10 time faster than manual cirmping
Multi-funtion operations
Portable and lightweight
Small bench top footprint
1. Connect foot perdal to the foot pedal joint
2. Connect the attaching plug to the power supply
3. Connect the grounding plug to the power supply
4. Turn on power switch
Picture one:
1. Screw off the phillips screws
2. Remove the protection cover
Picture two:
1.Embed the lower die
2.Screw on the phillips screws
3.Embed the top die
4.Screw on the phillips screws
Picture three:
1. Imbed the cable into the cable connector
2. Step down the foot pedal
3.Until crimping dies are closed completely
4. The crimping dies are automatically opened
5. Loosen the foot pedal
6. Take down the well-crimped cable joint
1. Pre-plug 2-in-one insulation and crimping dies
2. Coaxial crimping dies
3. Small brass crimping dies
4. Pre-Insulated Terminals crimping dies
We Provide
- Best products and factory price.
- On-time delivery and the shortest delivery time.
- 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
- OEM and customized service.
- User manuals will go with relative machines.
Service
- QC: All products will be checked before delivery.
- Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
- Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
- Operation Guidance: If you have any problem with operation, please feel free to contact us.
...
