Auto-cutting Machine (Multi-function, Bevel Cutter) BJ-150HX

Auto-cutting Machine (Multi-function, Bevel Cutter) BJ-150HX

Voltage: 220V

Power: 0.5kw

Cutting Length: 20-99999mm

Max. Cutting Width: 100(Straight)/35mm(Angle)

Cutting Speed: 120 p/min

Max Blade Temperature.: 420°C

Punching Dia: 2-5mm

Recommended Pressure: 20-50Mpa

Weight: 77.5kg

Stand Package Size: 800*570*615mm(L.W.H)

Application: All kinds of Woven Belt, Vel cro, Shoelace, Plastic soft tube, computer cable etc.

Multifunctional experience people-oriented service

Cutting machine with a variety of functions, adopt synchronous belt device with more stable tape loading, more accurate tape cutting. Automatic and efficient, this machine is equipped with receving device so that it’s easy for customer to pack. When cutting tapes, this machine can make holes with different diameters. So this is the machine that has multifunctions to meet customer’s diverse needs.

Product Detail

Cutting automatically, Operation easily, Application range widely, cutting edge smoothly without burr.

Special features

High Speed: It can cut 80-100 pcs per minute.(e.p. 100 mm long)

Accurate: Cut-length is accurate owing to a stepping motor.A sensor makes cut-length accurate by automatic sensing at set-position.

Multi-Angle: By use of multi-angle cut fuction of straight knife,it can cut many shapes as parallelogram, rhombic, trapeaoid, etc by only set the length, quantity, angle.

Punching Device: According to the needs of user, it can punching different size of the diameter of the holes.

Cutting Type: The blade is made of high quality steel. Hot cutter can cuttter can cutting ribbon, thin woven belt and the hot knife melts the end of the tape, cutting is sealed neatly, smoothly without fraying.

Automatic Operation: It works automatically only by setting length, quantity and angle.

Computerised: Automatic work, stop. The special fault self-diagnosis. direct show the fault problem on the screen, it will easy for you to find clear way to repair.

Automatic Stopper: It stops auto matically if materials run out during operation.

Memory: Set-length, set quantity&set speed are not erased even if power off&on.

Apllication

All kinds of Wovean Belts, Ve lcro, Shoelace, Plastic soft tuble, computer cablel et

Product Illustrations

We Provide

• Best products and factory price.
• On-time delivery and the shortest delivery time.
• 1-year warranty. If our products cannot function properly within 12 months, we'll offer spare parts for free; and you need to pay for the delivery.
• OEM and customized service.
• User manuals will go with relative machines.

Service

• QC: All products will be checked before delivery.
• Compensation: If any unqualified product is found, we'll pay the compensation or send new qualified products to customers.
• Maintenance & Repair: In case of any maintenance or repair need, we'll help to find out the problem and offer relative guidance.
• Operation Guidance: If you have any problem with operation, please feel free to contact us.

...
