Condition New
Application Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Automotives
Packaging Type Cartons
Packaging Material Paper
Automatic Grade Automatic
Driven Type Electric
Voltage 100v/115v or 230v
Power AC110V 60Hz / AC220V 50Hz
Place of Origin Japan
Brand Name BOJIN
Model Number TDA-080-NMSR
Dimension(L*W*H) 168*229*360mm
Weight 11kg
Certification CE
After-sales Service Provided No overseas service provided



New design ELM tape dispenser machine

Specifications

  • Features Automatically dispenses and cuts virtually any tape - including duct tape
  • Compact design and heavy duty metal construction, Safety interlock
  • 9" (251mm) maximum outside diameter roll
  • Digital push switch display for easy length adjustments
  • Adjustable feed intervals
  • Can dispense some non-adhesive materials
  • Switchable voltage (100v/115v or 230v)
  • Four operating modes (Manual / Auto Feed / Cut)

Width

13-80mm

Tape Size Set Limit

40 - 9999mm

Free Max. OD of Roll

230mm

Core Diameter

3" (76.2mm)

Accuracy

± 1mm

Power supply

AC110V 60Hz / AC220V 50Hz

Dimensions & Weight

229W x 168D x 360H 11kg









































Operation Video
/watch?v=CNQGYuodVPE





New design ELM tape dispenser machine

New design ELM tape dispenser machine





New design ELM tape dispenser machine

We Provide

  • Best products and factory price.
  • On-time delivery and the shortest delivery time.
  • 1-year warranty. If our products cannot function properly within 12 months, we'll offer spare parts for free; and you need to pay for the delivery.
  • OEM and customized service.
  • User manuals will go with relative machines.

Service

  • QC: All products will be checked before delivery.
  • Compensation: If any unqualified product is found, we'll pay the compensation or send new qualified products to customers.
  • Maintenance & Repair: In case of any maintenance or repair need, we'll help to find out the problem and offer relative guidance.
  • Operation Guidance: If you have any problem with operation, please feel free to contact us.

Related Automatic Tape Dispensers

Brand

Model

Cutting length

Cutting width

Outside diameter

Usable Tapes

Length Memory

Size (W×L×H) mm

Net Weight

BOJIN

M-1000

5-999mm

7-50mm

180mm

adhesive tape



137×218×150mm

2.4Kg

BOJIN

BJ-1000

5-999mm

5-50mm

180mm

adhesive tape



137x218x150mm

2.4Kg

BOJIN

BJ-2000S

5-999mm

5-50mm

180mm

adhesive tape

√

137x218x150mm

2.4Kg

BOJIN

M-1000S

5-999mm

5-50mm

180mm

adhesive tape



137x218x150mm

2.4Kg

BOJIN

ZCUT-2

13-60mm

3-25mm

130mm

adhesive tape



300×170×165mm

2.8kg

BOJIN

RT-3000

9-61mm

3-25mm

150mm

adhesive tape



120×150×250mm

2.2Kg

ELM

M-1000

20-999mm

7-50mm

180mm

adhesive tape



137x245x156mm

2.4Kg

ELM

MS-1100

30-999mm

7-50mm

180mm

adhesive tape



137×249×156mm

2.5Kg

ELM

TDA-080

40-999mm

13-80mm

230mm

adhesive tape



229×168×360mm

11.0Kg

ELM

TDA-080M

40-999mm

13-80mm

230mm

adhesive tape

√

229×168×360mm

11.0Kg

YAESU

ZCUT-7

5-999mm

6-50mm

300mm

Non/adhesive tape



116×140×213mm

2.8Kg

YAESU

ZCUT-8

9-61mm

3-25mm

150mm

adhesive tape



120×150×250mm

2.2Kg

YAESU

ZCUT-870

15-70mm

3-25mm

150mm

adhesive tape



126×150×258mm

2.2Kg

YAESU

ZCUT-9

5-999mm

6-60mm

300mm

Non/adhesive tape



116×140×213mm

1.6Kg

YAESU

ZCUT-9P

5-999mm

6-60mm

300mm

Non/adhesive tape

√

116×140×213mm

1.6Kg

YAESU

ZCUT-9RP

5-999mm

6-60mm

over 300mm

Non/adhesive tape



116×140×213mm

2.5Kg

ASUTECH

ED-100

5-999mm

7-50mm

180mm

adhesive tape



140×157×235mm

2.5Kg
