ED-100 Automated Tape Dispenser

ED-100 Automated Tape Dispenser thumbnail-1
ED-100 Automated Tape Dispenser photo-1
US$ 200 - 220 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Automotives
Packaging Type:
Cartons
Contact Supplier Request Quote Chat Now
Kunshan Bojin Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Automotives
Packaging Type Cartons
Packaging Material Paper
Automatic Grade Automatic
Driven Type Electric
Voltage 110V/220V
Power AC110V 60Hz / AC220V 50Hz 18W
Place of Origin Japan
Brand Name BOJIN
Model Number ED-100
Weight 2.5Kg
Dimension(L*W*H) 157*140*235mm
Certification CE
After-sales Service Provided No overseas service provided

ED-100 Automated Tape Dispenser





Features:

  • Ideal for medium to high production of repetitive taping for industrial applications;
  • Program a defined length and automatically advance and cut 2 Tape Rolls at the same time;
  • LED Digital length adjustment;
  • Blades good for up to over 200,000 cuts (dependent on type of material);
  • Cabinet made from flame retardant anti static composite;
  • Accuracy of cut length is +/- 1mm (dependent on type of material);
  • CE approved.

Specification:

  • Acceptable Tape Width: 7mm ~ 50mm
  • Cut Length: 15mm ~ 999mm
  • Display: 3 digit LED
  • Power Supply: AC110V 60Hz / AC220V 50Hz 18W
  • Size & Weight:  157*140*235mm; 2.5Kg

Instruction:

  • Preset a required length first, stick the tape tip to the outlet, and the tape will be cut automatically.
  • Auto mode and Manual mode are both available.
  • When a long tape is needed, keep pressing "FORWARD" key to the desired length, then press "CUT" key.
  • The cutter unit cassette can be removed and replaced easily (tape jamming can be also easily fixed).
  • The cutting length is shown on LED display, you can set the cutting length easily by "CM" or "MM" key.

ED-100 Automated Tape Dispenser

ED-100 Automated Tape DispenserED-100 Automated Tape DispenserED-100 Automated Tape Dispenser

ED-100 Automated Tape Dispenser

We Provide

  • Best products and factory price.
  • On-time delivery and the shortest delivery time.
  • 1-year warranty. If our products cannot function properly within 12 months, we'll offer spare parts for free; and you need to pay for the delivery.
  • OEM and customized service.
  • User manuals will go with relative machines.

Service

  • QC: All products will be checked before delivery.
  • Compensation: If any unqualified product is found, we'll pay the compensation or send new qualified products to customers.
  • Maintenance & Repair: In case of any maintenance or repair need, we'll help to find out the problem and offer relative guidance.
  • Operation Guidance: If you have any problem with operation, please feel free to contact us.

ED-100 Double Rolls Auto Tape Dispenser, double tape dispenser for short, is famous for its multiple functions. It can cut dual tape rolls with a required cut length at the same time. You may preset and define about 6 different length types for certain target length, and the auto tape dispenser will advance and cut the tape automatically.

Contact us for more about this double rolls auto tape dispenser ED-100!



Related Automatic Tape Dispensers

Brand

Model

Cutting length

Cutting width

Outside diameter

Usable Tapes

Length Memory

Size (W×L×H) mm

Net Weight

BOJIN

M-1000

5-999mm

7-50mm

180mm

adhesive tape



137×218×150mm

2.4Kg

BOJIN

BJ-1000

5-999mm

5-50mm

180mm

adhesive tape



137x218x150mm

2.4Kg

BOJIN

BJ-2000S

5-999mm

5-50mm

180mm

adhesive tape

√

137x218x150mm

2.4Kg

BOJIN

M-1000S

5-999mm

5-50mm

180mm

adhesive tape



137x218x150mm

2.4Kg

BOJIN

ZCUT-2

13-60mm

3-25mm

130mm

adhesive tape



300×170×165mm

2.8kg

BOJIN

RT-3000

9-61mm

3-25mm

150mm

adhesive tape



120×150×250mm

2.2Kg

ELM

M-1000

20-999mm

7-50mm

180mm

adhesive tape



137x245x156mm

2.4Kg

ELM

MS-1100

30-999mm

7-50mm

180mm

adhesive tape



137×249×156mm

2.5Kg

ELM

TDA-080

40-999mm

13-80mm

230mm

adhesive tape



229×168×360mm

11.0Kg

ELM

TDA-080M

40-999mm

13-80mm

230mm

adhesive tape

√

229×168×360mm

11.0Kg

YAESU

ZCUT-7

5-999mm

6-50mm

300mm

Non/adhesive tape



116×140×213mm

2.8Kg

YAESU

ZCUT-8

9-61mm

3-25mm

150mm

adhesive tape



120×150×250mm

2.2Kg

YAESU

ZCUT-870

15-70mm

3-25mm

150mm

adhesive tape



126×150×258mm

2.2Kg

YAESU

ZCUT-9

5-999mm

6-60mm

300mm

Non/adhesive tape



116×140×213mm

1.6Kg

YAESU

ZCUT-9P

5-999mm

6-60mm

300mm

Non/adhesive tape

√

116×140×213mm

1.6Kg

YAESU

ZCUT-9RP

5-999mm

6-60mm

over 300mm

Non/adhesive tape



116×140×213mm

2.5Kg

ASUTECH

ED-100

5-999mm

7-50mm

180mm

adhesive tape



140×157×235mm

2.5Kg
