Advanced Technology Exhaust Mine YBT Series Ventilation Fan

Jining Bafang Mining Machinery Co., Ltd.
Advanced Technology Exhaust Mine YBT Series Ventilation Fan thumbnail-1
Advanced Technology Exhaust Mine YBT Series Ventilation Fan thumbnail-2
Advanced Technology Exhaust Mine YBT Series Ventilation Fan thumbnail-3
Advanced Technology Exhaust Mine YBT Series Ventilation Fan thumbnail-4
Advanced Technology Exhaust Mine YBT Series Ventilation Fan thumbnail-5
Advanced Technology Exhaust Mine YBT Series Ventilation Fan photo-1
Advanced Technology Exhaust Mine YBT Series Ventilation Fan photo-2
Advanced Technology Exhaust Mine YBT Series Ventilation Fan photo-3
Advanced Technology Exhaust Mine YBT Series Ventilation Fan photo-4
Advanced Technology Exhaust Mine YBT Series Ventilation Fan photo-5
US$ 500 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Electric Current Type:
AC
Mounting:
Ceiling Fan
Blade Material:
Cast Iron
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Daliam Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type AC
Mounting Ceiling Fan
Blade Material Cast Iron
Place of Origin Shandong, China
Brand Name Bafang
Model Number YWF
Voltage 380V
Power 2.2KW
Air Volume 20CFM-420CFM
Speed 2300RPM-3000RPM
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Advanced Technology Exhaust Mine YBT Series Ventilation Fan

Product Description



Product Introduction

Axial Flow Blower  axial fan  AC blower  Ventilator  Exhaust Fan Mine ventilation fan  motor fan

Application:  Underground mining, tunnel, metal mining,  chemical mining, industrial
Function:  explosion-proof, built-in muffler, extraction local ventilation fan
Temperature range:-20C~+40C
Match Motor: YB series II  Y motor, 380v/660v motor, independent motor but large air capacity
MOQ: 1 PCS
Lead time: 10 days

Main Parameter

Model

YBT-2.2

YBT-5.5

YBT-7.5

YBT-11

YBT-18.5

YBT-22

YBT-30

Full pressure(Pa)

960-380

1700-800

1900-900

2250-800

2400-520

3200-680

3500-800

Air capacity(mmin)

55-101

90-180

100-210

130-240

195-300

240-370

250-800

Efficiency(%)

76

76

80

80

80

80.0

80

dB(A) Level

87

89

89

91

95

95

95

Diameter(mm)

315

400

500

560

600

600

630

Power(KW)

2.2

5.5

7.5

11

18.5

22

30

Voltage (V)

380

380

380

380

380

380

380

 Figure Photos                                                                                          Advanced Technology Exhaust Mine YBT Series Ventilation FanAdvanced Technology Exhaust Mine YBT Series Ventilation FanAdvanced Technology Exhaust Mine YBT Series Ventilation FanAdvanced Technology Exhaust Mine YBT Series Ventilation FanAdvanced Technology Exhaust Mine YBT Series Ventilation Fan
