CDH-Y Hydraulic buffer slide car stopper/train stopper/rail stopper
Main Parameter
1.The maximum impact speed allows vehicles:
According to user needs, can provide 15 km/h, 20 km/h, 25 km/h, 30 km/h, a total of four class.
2.The total resistance of buffer stops:
According to user needs, can provide 30 t, 45t, 60 t, 75 t, a total of four class.
3.The buffer head center distance on the surface of the rail height:
Standard rail vehicles: 850 mm. The subway and light rail vehicles: 500 mm, 660 mm, 678 mm and 720 mm. Other vehicles provided by the user data, designed according to actual situation.
4.The buffer head geometry shape and size:
Standard vehicle for planar, subway, light rail and other vehicles, and provide the coupling of the size and shape matching.
5.The hydraulic oil cylinder buffer resistance:
Match the total resistance of buffer stops, and respectively ≤30t,45t,60t,75t,a total of four class
Figure Photos
