Specification
concrete road paver machine
1.the roller can be changed according to work need.
2.weight:1500kg.
3.driving speed:8-10m/min.
Concrete road paver machine
Description
1.with a steel structure ,the whole frame is solid and shock resistant.
2.the roller can be changed according to work need.
3.Concrete road paver machine is control by electric equipment,one person can control the
machine to finish the road pavement
4.Four-axel concrete paver leveling machine has three axes, a section responsible for walking,
a section responsible for leveling, a section responsible for pulp.the machine is added a set
of circular leaf plate leveling device in the front of main machine,The excess mixture will be
rolled to produce internal compression by rotating each blade for promoting the concrete road
uniform and stability.
Technical data
| shaft length | 3-8m |
| shaft diameter | 219mm |
| driving speed | 5-7m/min |
| pavement thickness | 200-300mm |
| excing frequency | 48Hz |
| exciting force | 4.2KN |
| Power | 5.5-11kw |
| Weight | 1500kg |
Detailed Picture
