Specifications
Easy to functionMQ1WG6.3-120FC-Z
Engine
Engine type: Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine
Bore*stroke[mm(in)]: 86*70(3.39*2.76)
Dispiacement[ml(cu. In)]: 406(24.78)
Rated output power[kW(HP)/rpm]: 6.3(8.57)/3600
Fuel: 0#or-10#light diesel oil
Fuel tank volume[L(gal. )]: 5.5(1.21)
Fuel consumption rate[g(ml)/kW. H]: 281(334)
Lubrication oil volume[L(gal. )]: 1.65(0.36)
Engine PTO: Camshaft
Air cleaner model: Semi-dry, oil bath, foam filter element
Starting system: Recoil
Tiller
Gear shifting: -1, 0, 1, and 2
Driving model: Gear
Tilling scope: 1100-1200mm
Tilling depth: ≥100mm
Working efficiency: ≥400m2/h
Packing
Body size: 1770*975*940mm (tyre size: Φ400mm)
Packaging size: 1030*570*880mm
N. W /G. W: 126/130kg (including tri-blades cutter)
20FT(set): 50.
| Basic Parameter | |
| Equipped engine | 186 air-cooling diesel engine |
| Engine power | 6.3KW |
| Ignition mode | pressing ignition |
| Starting mode | hand pulling, kick, automatic |
| Driving mode | gear driving |
| Transmission shifting | 2,0,1,reverse |
| Tilling width (mm) | 1000-1100 |
| Tilling depth(mm) | 150-250 |
| Technic Parameter | |
| Tilling efficiencym2h | ≥500 |
| Full set weight (kg) | 120 |
| Overall dimension | 1770*975*940mm |
