Place of Origin Fujian, China
Brand Name GM
Model Number YT24
Type Air Drill
Average Air Consumption 66.7 L/S

YT24 Pneumatic air leg drill

The rock drill is a kind of high efficiency air leg rock drill machine.It is widely used for blasting holes and other drilling projects in a quarries, railway construction, water conservancy construction and defence project facility.

It  suitable for drill level or gradient holes in medium hard or hard rock(f=8-18).The drilling depth can be five-eight meters. It can be matched with the FT140BD short air-leg or FT140B long air-leg to use in the basis of the width of rock.Also it can be fixed on drilling-vehicle or drilling-shelf.

To ensure the well lubricating.This rock drill may match FY200B oil reservior .

Weight                                                   ≈ 24 kg

Length                                                  678mm

Cylinder dia                                           70mm

Piso stroke                                           70mm

Air pressure                                             0.4—0.63MPa

Impact frequencey                                        ≥ 31Hz

Air consumption                                        ≤66.7 L/S

Air pipe (inner dia)                                             19mm

Water pipe (inner dia)                                         13mm

Shank head dia                                            34-42mm

Shank dimensions(hex×length)                     22×108 mm±1mm

FT140B Air-leg:

Length of air-leg                                            1687mm

Pushstroke                                                 1250mm

Cylinderdia                                                 60mm

Weight                                                  ≈15.6kg

FT140BD Air-leg:

Lengthofair-leg                                            1400mm

Push stroke                                               965mm

Cylinderdia                                                  60mm

Weight                                                 ≈13.9kg

FY200B Oil reservior:

Capacity                                               200milliliter
