PVC Steel Wire Reinforced Hose
Tube: Non-toxic clear flexible PVC.
Reinforcement: Strong and flexibility steel wire spiraled
PVC Steel Wire Reinforced Hose
Application: Widely used for sucking or discharging of water, oil, weak chemicals and powders in industry, agriculture, factory, mining and building etc.
Tube: Non-toxic clear flexible PVC.
Reinforcement: Strong and flexibility steel wire spiraled.
Cover: Non-toxic clear flexible PVC.
Characteristics: Strong, abrasion resistant, corrosion resistant and weather resistant, Its of stability and flexibility under performance.
Temperature range: -5ºC - +65ºC (+23ºF to+149ºF)
Technique parameter:
Inside Diameter | Outside Diameter (mm) | Reinforced Layer(B) | Working pressure (MPa) | Burst pressure (MPa) | Length(m) | Weight (kg/m) |
Packing measurement | |
inch | mm | D×H(mm) | ||||||
1/4 | 6 | 11 | 2.5 | 0.7 | 2.1 | 100 | 0.115 | 470×130 |
5/16 | 8 | 14 | 3.0 | 0.7 | 2.1 | 100 | 0.156 | 500×130 |
3/8 | 9 | 15 | 3.0 | 0.7 | 2.1 | 100 | 0.17 | 550×150 |
1/2 | 12 | 18 | 3.0 | 0.6 | 1.8 | 100 | 0.22 | 550×170 |
5/8 | 15 | 22 | 3.5 | 0.6 | 1.8 | 100 | 0.305 | 650×200 |
3/4 | 19 | 26 | 3.5 | 0.6 | 1.8 | 50 | 0.38 | 650×150 |
1 | 25 | 33 | 4.0 | 0.6 | 1.8 | 50 | 0.547 | 700×200 |
1- 1/4 | 32 | 41 | 4.5 | 0.5 | 1.5 | 40 | 0.85 | 800×170 |
1- 1/2 | 38 | 48 | 5.0 | 0.5 | 1.5 | 40 | 1.2 | 850×210 |
2 | 50 | 62 | 60 | 0.5 | 1.5 | 40 | 1.6 | 980×250 |
2- 1/2 | 63 | 80 | 8.5 | 0.4 | 1.2 | 30 | 3.0 | 920×240 |
3 | 75 | 92 | 8.5 | 0.4 | 1.2 | 30 | 3.9 | 1020×280 |
3- 1/2 | 89 | 107 | 9.0 | 0.4 | 1.2 | 30 | 4.5 | 1100×330 |
4 | 102 | 120 | 9.0 | 0.3 | 0.8 | 30 | 5.2 | 1100×470 |
5 | 127 | 141 | 7.0 | 0.2 | 0.6 | 20 | 5.0 | 1140×430 |
6 | 152 | 166 | 7.0 | 0.2 | 0.6 | 20 | 6.0 | 1700×130 |
Note: 1MPa=10bar≈145psi≈10kgf/cm²
