Help CenterHCN Mini 0104 Series Mini Skid Steer Loader 4 in 1 Bucket
Related Products
-
HCN Mini 0104 Series 4 in 1 Bucket for Dingo Mini LoaderUS$ 900 - 3,000MOQ: 1 Set -
HCN Brand 030801 Series Used Mini Diggers With ISO and GOSTUS$ 500 - 2,000MOQ: 1 Set
-
HCN Brand 0102 Series Pallet Fork for Skid Steer LoaderUS$ 100 - 1,000MOQ: 1 Set
-
HCN Brand 0505 Series Tractor Land Levelers With ISO and GOSTUS$ 100 - 500MOQ: 1 Set
-
HCN Brand 0505 Series Skid Steer Loader With Land LevelerUS$ 100 - 500MOQ: 1 Set
Specifications
1.Mini Skid Steer Loader With 4 in 1 Bucket,mini skid steer loader 4 in 1 bucket,4 in 1 bucket for mini skid steer loader
Product Descriptions:
- mini 4 in 1 bucket is used to grab teeth profiled on both front/rear overlap for greater grip of logs or other debris.
- Side curved sections create greater opening bucket width of 860mm.
- 1 Piece heavy duty 6mm grill/hungry board with unique high visibility design, for clear vision of both front and back bucket edge.
- Standard Heavy Duty 20mm Floors
- Optional reversible bolt on cutting edges for all 3 edges of the bucket.
- Optional chisel or tiger teeth with pin on design.
- Full Range from 880mm to 2130mm
- 12mm and 16mm floors available on request.
- mini Skid Steer Loader With 4 in 1 Bucket,mini skid steer loader 4 in 1 bucket,4 in 1 bucket for mini skid steer loader
Application Field:
the mini 4 in 1 bucket is used to grading, scraping, grappling, dozing dirt or material spreading most construction work.
Technical Specifications:
The detailed specs of the mini 4 in 1 bucket are listed as follows:
| Model of 4 in 1 bucket | 010443 | 010460 | 010466 | 010472 |
| overall width(mm) | 1050 | 1584 | 1736 | 1880 |
| overall length(mm) | 600 | 768 | 768 | 768 |
| overall height(mm) | 720 | 879 | 879 | 879 |
| open distance(mm) | 554 | 718 | 718 | 718 |
| pressure(mpa) | 21 | 20 | 20 | 20 |
| clamp force(n) | 207 | 8230 | 8230 | 8230 |
| overall weight(kg) | 118 | 385 | 420 | 460 |
| capacity(cbm) | 0.17 | 0.4 | 0.44 | 0.48 |
More Photos:
the standard steel frame package by FCL or LCL
1 year for the main parts like motors,cylinders.
Xuzhou HCN Machinery Technology Co.,Ltd. subordinated to HCN Technology Group Co.,Ltd, which is a high-tech enterprise, advanced unit in the domestic construction machinery industry and one of road machinery technological innovation and exchange center corporate.
The company is located in Economic Development Zone, Jinshan Bridge, Xuzhou City, with beautiful scenery, convenient transportation and elegant environment, covering an area of 12847.2 square meters, more than 120 employees, including over 40 technical personnel, who re responsible for product development and design, design verification, product testing, performance testing and other work, played a huge role in R & D reliable performance, technologically advanced quality products.
Main products are: skid steer loaders,wheel loaders,forklifts and their attachments.
