Hot sale 2-ton mini wheel loader with 1.1 cube meter bucket
*YTO diesel engine is adopted, with strong power.--
*Applying hydrodynamic transmission technology, single stage, 3 elements torque converter owns simple structure and high reliability.
*Controlled by flexible shaft, hydraulic power shift gearbox with 2 forward and 2 reverse gears makes operation easy.
*Single pump, split flow working hydraulic system makes lower consumption and excellent performance.
*Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoiding oil leakage;
*Load sensing fully hydraulic steering system makes operation easy.
*Air over hydraulic brake system; Caliper disc brakes.
*Working device with automatically leveling ability at high position.
*Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
*Integral, luxury instrument board.
*New, luxury cabin.—
Items |
Specifications |
Items |
Specifications |
Bucket capacity |
1.1 m3 |
Min. turning radius |
4600mm |
Rated load |
2000 kg |
(outside of rear wheel) |
|
Dumping height |
2750 mm |
Steering angle |
35º each direction |
Dumping reach |
920 mm |
Min. ground clearance |
320mm |
Bucket lifting time |
5 S |
Wheel base |
2350mm |
Total cycle time |
9 S |
Tread |
1500mm |
(lifting+ dumping+ lowering ) |
Engine model |
LR4018G |
|
Max. travel speed |
25km/h |
Rated engine power |
60kW@2400rpm |
Max. breakout force |
55 kN |
Tire |
16/70-20 |
Max.drawing force |
45 kN |
Overall dimensions (L*W*H) |
5880*2060*2750mm |
Max. grade ability |
30° |
Operating weight |
6000kg |
wheel loader Packaging and shiping in 20 ft container or 40 ft container.Professional Packing makes delivery safe in container.
Our services : Provide good quality machinery in China and spare parts for your machines from China .ZF transmission 4WG200/6WG200 and parts,Hanzhou Advance(Hanchi advacne) 4WG180/6WG180, Weichai ,Yuchai ,Shangchai Engine & Parts.All SDLG parts are available and fast delivery in China.
SHANDONG SENXIN TRADE CO.,LTD has been in this sector for 14 years , mainly exporting and distributing China faoums construction machinery and parts , Brands including SDLG , XCMG , LIUGONG , XGMA , CHENGGONG , CHANGLIN , SHANTUI , etc .
Our products:
Wheel loader , Hydraulic excavator ,Motor Grader ,Backhoe loader ,Road roller ,Skid steer loader ,Truck crane
Full series parts for those machine are available , please provide parts number to us when you go for the parts.
Engine Parts:
Wechai(WD615,WP6G,td226b...) ,shangchai(C6121) ,Yuchai ,Xichai ,Xinchai ,Cumm1ns.
