SINOTRUK HOWO TRACTOR TRUCK 4x2 for Sale

SINOTRUK (CNHTC),  HOWO Tractor Truck Euro 2 Emission Standard

Model

ZZ4187M3511W

ZZ4187N3511W

ZZ4187S3511W

ZZ4187V3511W

Cab

HW76Lengthen cab,single bunk

Model

WD615.62/WD615.87

WD615.69

WD615.47

D12.42

Engine Hp

266/290

336

371

420

Transmission

HW15710

HW15710

HW19710

HW19710

Front axle

HF7

HF7

HF7

HF7

Rear axle

ST16/MCY13

ST16/MCY13

ST16/MCY13

ST16/MCY13

Steering

ZF8098

ZF8098

ZF8098

ZF8098

Tyres

12.00R20

12.00R20

12.00R20

12.00R20

Fifth wheel

50#/90#

50#/90#

50#/90#

50#/90#

Dimensions (mm)

Overall length*width*height

6110x2496x2958

Wheelbase

3500

Weight (kg)

Kerb weight

7180;7230

Gross vehicle weight (GVW)

18000

Front axle loading capacity

7000

Rear axles loading capacity

16000

Performance

Maximum driving speed (km/h)

102

Cab

SINOTRUK HW76 Lengthen cab,single bunk,safety belts,left hand driving,air conditioner.Option:right hand driving;Wind guide cover

Engine

Model

WD615.62/WD615.87

WD615.69

WD615.47

D12.42

Horsepower

266/290

336

371

420

Kw/r/min

196/2200

247/2200

273/2200

309/2000

Maximum output

213/2200

Bore/Stroke

126x130mm

126x130mm

126x130mm

126x155mm

Valve

2

2

2

4

Displacement

9.726L

9.726L

9.726L

11.596L

Type

6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection

Transmission

SINOTRUK HW15710 or HW19710 transmission ,10 forward and 2 reverse

Front Axle

SINOTRUK HF7 Front Axle,new 7-ton front axles of equipped with drum brakes.Option: disc brake

Rear Axles

SINOTRUK ST16 Double Reduction Drive Axle, Pressed axle housing, central single reduction with planetary wheel reduction and

with differential locks between wheels and axles,ratio: 3.93 or 4.42;4.8

SINOTRUK MCY13 Single Reduction Drive Axle, ratio: 3.36 or 3.70,4.11

Steering

German ZF8098 Steering Gear Box ,hydraulic steering with power assistance,Ratio:22.2-26.2,18.5MPa

Tyres

Rims:8.5-20,10 hole-steel;Tyres:12.00-20 diagonal tyre with 1 Spare tire

Option:12.00R20 radial tyre;295/80R22.5 tubeless;12R22.5 tubeless;315/80R22.5 tubeless

Oil Tank

D type-400L Aluminum alloy fuel tank

Fifth wheel

50# (2 inch);90#(3.5 inch)

Optional

Vertical Muffler;ABS;Automatic Break Clearance Adjusting Arm;Traveling Data Recorder;Metal Pipeline;Engine Protective Board
