best quality portable diesel generator for sale

FOB Price

US$ 200 - 500 / Set

10 Sets(Min. Order)

Port CHONGQING SHANGHAI SHENZHENG
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Chongqing, China	Brand Name	TENGLONG POWER
Model Number	TL-DIESEL	Output Type	Other, 1 OR 3 PHASE
Speed	3600	Frequency	50/60Hz
Rated Power	3KW-10KW	Rated Voltage	110/230V
Rated Current	8.3A

Product Description

Specifications

1.Trusted partner
2.Stable voltage and current
3.100% Copper Winding
4.Recoil or electric start
5.Low fuel consumption

Factory Spec

Factory Spec

First manufacture in Chongqing for gasoline/kerosene/LGP Engines, Generator sets, Water pumps andTillers /Cultivators. With more than 10 years experience in general power industry since 1998.

Certifications

Socket and Plug

More choice

MODEL

TL1000 (1.0KW)

TL1200 (1.2KW)

TL2.0GF(D) (2.0KW)

FREQUENCY (Hz)

50/60

MAX/RATED OUTPUT(KW)

0.9/0.8

1.1/1.0

2.2/2.0

RATED VOLTAGE(V)

110/230

POWER FACTOR

PHASE

1 PHASE

VOLTAGE REGULATOR

Capacitance Compensation

AVR

ENGINE

TL154FA/P(3.0HP)SV

TL154F/P(3.0HP)OHV

TL170F/P(7.0HP)

PACKING (LxWxH) (mm)

445x355x400

480x375x430

620x450x460

N.W.(Kg)

45(48)

STARTING SYSTEM

RECOIL

RECOIL/ELECTRIC

FUEL CAPACITY (L)

RUNNING HOURS (H)

ALTERNATOR TYPE

BRUSHLESS

BRUSH

OIL ALERT

INSTALLED

BATTERY

OPTIONAL 7AH

DC OUTPUT 12V 8.3A

OPTIONAL

FUEL TYPE

GASOLINE

GASOLINE/KEROSENE/LPG

ALTERNATOR MATERIAL

100% COPPER

MODEL

TL2.5GF(D) (2.5KW)

TL2.8GF(D) (2.8KW)

TL3.0GF(D) (3.0KW)

TL4.0GF(D) (4.0KW)

FREQUENCY (Hz)

50/60

MAX/RATED OUTPUT(KW)

2.8/2.5

3.0/2.8

3.3/3.0

4.2/4.0

RATED VOLTAGE(V)

110/230

POWER FACTOR

PHASE

1 PHASE

VOLTAGE REGULATOR

AVR

ENGINE

TL170F/P(7.0HP)

TL177F/P(9HP)

TL190F/P(15HP)

PACKING (LxWxH) (mm)

620x450x460

700x535x575

N.W.(Kg)

47(49)

48(50)

73(75)

79(81)

STARTING SYSTEM

RECOIL/ELECTRIC

FUEL CAPACITY (L)

RUNNING HOURS (H)

ALTERNATOR TYPE

BRUSH

OIL ALERT

INSTALLED

BATTERY

OPTIONAL 7AH

OPTIONAL 9AH

DC OUTPUT 12V 8.3A

OPTIONAL

FUEL TYPE

Gasoline/Kerosene/LPG

ALTERNATOR MATERIAL

100% Copper

MODEL

TL5.0GF(D) (5.0KW)

TL5.0GFS(D) (5.0KW)

TL6.5GF(D) (6.5KW)

TL6.5GFS(D) (6.5KW)

FREQUENCY (Hz)

50/60

MAX/RATED OUTPUT(KW)

5.5/5.0

7.0/6.5

RATED VOLTAGE(V)

110/230

400

110/230

400

POWER FACTOR

0.8

PHASE

1 PHASE

3 PHASE

1 PHASE

3 PHASE

VOLTAGE REGULATOR

AVR

ENGINE

TL190F/P(15HP)

PACKING (LxWxH) (mm)

700x535x575

N.W.(Kg)

79(82)

80(83.5)

80(84)

STARTING SYSTEM

RECOIL/ELECTRIC

FUEL CAPACITY (L)

RUNNING HOURS (H)

ALTERNATOR TYPE

BRUSH

OIL ALERT

INSTALLED

BATTERY

OPTIONAL 9AH

DC OUTPUT 12V 8.3A

OPTIONAL

FUEL TYPE

GASOLINE/Kerosene/LPG

GASOLINE/LPG

ALTERNATOR MATERIAL

100% Copper

MODEL

TL9500(D) (7.0kw)

TL9500S(D) (7.0kw)

TL11000 (D)

TL11500S(D)

FREQUENCY (Hz)

50/60

MAX/RATED OUTPUT(KW)

7.5/7.0

10.5/8.0@50Hz;11/10@60Hz

12.5/11.5(KVA)@50Hz;

13.5/12.5(KVA)@60Hz

RATED VOLTAGE(V)

110/230

380

110-240

200-415

POWER FACTOR

0.8

0.8/lag

PHASE

1 PHASE

3 PHASE

1 PHASE

3 PHASE

VOLTAGE REGULATOR

AVR

AVR,±1.5% @ Rated Speed

ENGINE

TL192F/P(16HP)

2V78,V-Shape Dual-Cylinder, Forced Air-Cooling 4 Stroke, OHV

PACKING (LxWxH) (mm)

700x535x575

960 X 630 X 760 ( Pallet Included)

N.W.(Kg)

92(95)

151

STARTING SYSTEM

RECOIL/ELECTRIC

Electric start

FUEL CAPACITY (L)

RUNNING HOURS (H)

7.5

ALTERNATOR TYPE

BRUSH

Brush, Self-Excitation System

OIL ALERT

INSTALLED

BATTERY

OPTIONAL 9AH

YES

DC OUTPUT 12V 8.3A

OPTIONAL

YES

FUEL TYPE

Gasoline

ALTERNATOR MATERIAL

100% Copper

Products Exhibition

Packaging & Shipping

1 set in a polybag, standard carton box.

Customer designed packing method available.

FAQ

1. MOQ ?

A: For different products, we take MOQ: Engines: 30sets; Generator: 10sets; Water Pump: 20sets ; Tiller: 10sets

2. Price Terms?

A: EXW, FOB, CNF available.

3. Payment Terms?

A: T/T, L/C, D/A, D/P ,Alipay

4. Delivery?

A: For ordinery prodcuts: 7-10 working days finish at factory.

5. Shipping?

A: We are located in Chongqing, China. river & ocean combined transportation, about 15 days longer than ocean transportation from Shenzhen, Shanghai.....

If you have any other questions and i am offline, just get in touch with me by QQ:747158287
