Plant direct sale fire small the sawdust briquette charcoal making machine
Renewable trustworthy bioenergy fuel used sawdust briquette machine sawdust briquette charcoal making machine
1. The Brief Description of machine to sawdust briquette charcoal making machine
Sawdust and wood waste is the commonest so called rubbish in sawmill,but it is good biomass material.Briquetteing is the way to convert loose biomass materials,such as sawdust,straw,and rice husks into high density solid blocks or bars that can be used as efficient fuel.Sawdust and wood waste is one of the best material for high pressure briquetteing mainly because sawdust contains a high proportion of lignin,which functions as glue when briquetting,and that sawdust doesn't need to be ground before briquetting.
bio fuel briquettes machine is to use jute sticks,sawdust,crop straw,husk etc.biomass material,raw materials through wood grinder under the action of the propeller and the heating coil temperature and high pressure area will form a loose processed into hollow rods.The product has a large density,small volume,combustible,and can replace firewood and coal.General product outer diameterof 50-80mm,aperture 15-20mm,a hollow quadranular or hexagonal prism.It can be used as fire wood with long time buring and it can be make into wood charcoal by carbonization furnace.
Details of our machine to sawdust briquette charcoal making machine
1) Control panel:
Three meters:Therometer,Voltmeter,Ammeter
Three main buttons:On,off,Rev,Urgent brake
Therometer(0-500°):adjust the surface carbonization of final rod.
Rev button:Under jam condition to press
2) Motor: AC motor 11-18.5Kw 380V 50Hz power consumption<100kwh/t
3) Power belt:4 combined quality belts our OEM is durable
4) Material:Recommended Moisture:8-12%
Requested particle size≤ 6mm
Wood crusher without dust is available: hnyxzg.en.china.cn
Wood dryer system is available:hnyxzg.en.china.cn
5) Inlet:Put the material into the inlet
Automatic closed type conveyor is available : hnyxzg.en.china.cn
6) Vent:The final rod is hot with gas so this vent is necessary.
7) Outlet
The final rod will out here with the length you need.
We have many kind of forms: like hexagonal,quadrangular round.
If you any special request,our engineer can adjust the pattern in advance.And it is easy to change pattern.
2.Advantage of machine to sawdust briquette charcoal making machine
1).The design is reasonable,reliable quality,simple structure,easy operation,less landing,investment,labour,energy saving feature.Screw press ZBJ wood charcoal briquette machine is popular by high efficiency and economic
2).The design of the automatic control of electric heating devices is helpful to randomly adjust the humidity of materials to ensure the material forming stable,improve work efficiency.
3).For a variety of biomass raw materials pressing,and energy consumption,high production efficiency.
3.Our feature of machine to sawdust briquette charcoal making machine
1).The our screw press ZBJ bio machine replaces the three bearings by four,increasing the stability and durablility of machine to reduce the abnormal sound during operation.
2).Improving the oil lubrication system from applying oil into oil bath.Mantaince is easier.
3).Increasing the pitch of main screw to change the feed rate,the output and the production rate is highly increased.
4).Improving the structure of the forming cylinder,reducing the mechanical friction with the material,increase the density of the final products
5).The key parts of the product with a wear-resisitant material with special treatment,it is possible to suppress the production of containuous and durable.
6).The pressure of 210 tons,1.4Mpa and make the density between 1.3-1.5ton/m³.
4. Raw Materials of machine to sawdust briquette charcoal making machine
Jutestick,Sawdust, crop straw, wood branches, rice hull, bamboo sawdust, peanut shell, coconut shell, sunflower shell, furfural dregs, cotton stalks, corn stalks, sesame straw, corncob and so on.
4.Main Technical Parameters of sawdust briquette charcoal making machine
| Model | Capacity(kg/h) | Heating ring(kw) | Dimension(mm) | Weight(kg) | Power(kw) |
Diameter of final rod(mm) |
| YXZB-11 | 130-150 | 1.5(3pcs) | 1650*600*1260 | 700 | 11 | 50 |
| YXZB-15 | 200-250 | 2(3pcs) | 1850*700*1260 | 850 | 15 | 60 |
| YXZB-18.5 | 300-400 | 3(3pcs) | 1860*800*1360 | 850 | 18.5 | 70-80 |
5.The Produce Flow Chart of sawdust briquette charcoal making machine
1) Step 1- Crushing: crush the raw materials into small pieces (around 3MM diameter) by wood crusher/Hammer Mill;
For more detailed information>>
2) Step 2- Drying: dry the crushed materials by flash dryer to reduce the crushed material's moisture content below 12%;
For more detailed information>>
3) Step 3- Briquetting: Put the dried materials into the briquette machine to make sawdust briquettes.
4) Step 4- Carbonizing: Put finished sawdust briquettes into the Carbonization Stove to convert the sawdust briquettes into charcoal briquettes.
More details of machine to sawdust briquette charcoal making machine
Sapre parts of the sugarcane bagasse briquette machine
Packing and delivery
Packaging Details:Yuxiang brand screw press ZB biomass briquetting machine packing detail:
- 1. all the machines will be wrapped up with plastic film first (including the motor).
- 2. The plastic film bag wrapped machine, according to the size and weight to make wooden or iron box, put machine in and fixed the box after loading. (The box material can be made as your requirements) 3. The machine parts need to be put in a fixed container, should be fixed well, lest collision and wear, or lost.
Delivery Detail: Within 10 days after receiving deposit
8. Customers visiting
Gongyi city Yuxiang Heavy Machinery Co,Ltd has established more than 20 years, our mainly product Mining series equipment, Charcoal briquette machine series, Carbonization furnace equipment, Dryer series equipment, Grinding machine series,oil press machine/oil filteration machine etc.
FAQ:
1. Does it will produce smoke during the production?
The working principle of screw press ZB biomass waste briquette machine is to press the biomass material and heat the surface to form,so there will be small smoking with vapour if you adjust the heat coil to high temperature to carbonize the surface of final product.Usually the smoke is small,if you need,an install a equipment to let the smoke into the water and absorb the smoke.
2. What is the fineness of the sawdust i can use to make charcoal?
Generally, below 5mm is ok. but such as wood shaving, rice husk. 8mm is also no problem
3. Can I build the carbonization kiln to carbonize by ourselves?
Yes, you can. Our engineer will provide the drawing for you free of charge.
4.Is it easy to operate?
Yes,three main buttons on the panel:On,off,Rev,Urgent brake.So it is easy to control.
