2015 the NO.1 Production of sawdust wood shavings machine for wood sawing
Brief introduction of the machine :
This machine is special equipment for producting high-quality sawdust,compared to general crusher,sawdust machine has the
advantages of low investment, low energy consumption,high productivity,good economic returns,operation and repair convenient.
Sawdust machine widely used in paper making ,edible fungus,mechanism charcoal ,sawdust broad ,high density board,MDF industry
raw material crusing machine processing link. The series equipment is suitable for flow operation ,is widely used in preparing process
for samll and and medium particle board and fiber production enterprises,can also be used for self-employed for the production of
wood products.
The pictures of the machine show:
Characters of the machine
- Rational design, compact structure, safe and durable, high productivity;
- It is driven by only one motor;sawdust wood shavings machine
- Low noise, simple structure, compact layout, competitive price;
- Stable work, low consumption, high efficiency, high quality, low cost.
Structure of the machine
1) It is composed of machine body, knife chipping part, chips re-crush part and sieving part ,ect. sawdust wood shavings machine
2) It combines both chipping and crushing in one machine, can make sawdust in one passage,
no need to use wood chipper for preprocessing of wood logs.
3) To ensure security, the feed inlet of this crushing equipment adopts self-sction design to avoid serious damage to operators.
Technical data of the machine
| Model | Weight(kg) | Speed(r/min) | Power(kw) | Capacity(kg/h) | Blade(piece) |
| 420 | 160 | 2800 | 11-15 | 400-1500 | 4 |
| 500 | 238 | 2800 | 15-18.5 | 800-2000 | 4 |
| 600 | 360 | 2800 | 22-30 | 1000-2500 | 4 |
| 700 | 480 | 2800 | 30-37 | 1500-3000 | 6 |
| 800 | 640 | 2800 | 37-45 | 2000-4000 | 6 |
| 1000 | 1100 | 2800 | 55+7.5 | 2500-4500 | 8 |
| 1200 | 1600 | 2800 | 75+7.5 | 3000-5000 | 9 |
| 1500 | 2400 | 2800 | 90+7.5 | 3500-6000 | 12 |
Working principle of the machine
Sawdust shavings machine (sawdust crusher) adopts blade cutting and high speed flow, collision and double crush functions can be
completed in one machine , can separate particulate at the same time.During cutting, rotor produces high speed airflow, rotating along with the blade cutting direction, materials speed up in the airflow, repeated shocks, make materials
double crushed, accelerated material crushing rate. sawdust wood shavings machine
The application in industry :
our service :
our customers:
our factory:
We can equip the line according to your practical situation. If you have plan to
visit China, warm welcome to visit our factory! We have plenty of video and pictures
as your reference.
