Specifications
paste and liquid filling machine1.good quality and after-sales service
2.easy operation
3.great performance
Filling machine for paste and liquid
Work principle of liquid filling machine:
A. Through the cylinder's movement of forward and backward to make the piston which is located in the cylinder do reciprocating movement, so as to occur the negative pressure in the preceding chest of the cylinder
B. The piston is pulled backward when the cylinder make forward movement, the material cylinder occurred negative pressure, the materials in the barrel are pressed into the feeding pipe by pressure and go into the material pipe through unidirectional valve of feeding and discharging materials.
C. The piston is driven forward when the cylinder make backward movement, the materials are pressed and go into discharging pipe through unidirectional valve of discharging materials, finally filled into the empty bottle which need to be filled, then one time filling finished.
D. It is a single and simple action to each time of filling for the piston filling machine, so it has very high filling precision and stability to every regular container
Features of liquid filling machine:
1.The liquid filling machine cylinder, cabinet, hopper are made of stainless steel ,and the piston made of PTFE material pneumatic parts are imported components, compliance with GMP requirements.
2.Paste filling machine filling volume and filling speed can be adjusted, with a foot switch and auto- filling features.
3.Paste filling machine with high precision, simple structure, convenient operation.
Application of liquid filling machine:
This series of horizontal pneumatic semiautomatic paste filling machine widely used for chemical, food, cosmetic, pharmaceutical, pesticide, oil and other industries liquid, paste, sauce, granular materials’ quantitative filling.
Technical parameter of liquid filling machine:
Single-head:
Model | JF-I-60 | JF-I-125 | JF-I-250 | JF-I-500 | JF-I-1000 | JF-I-2500 | JF-I 5000 |
Air supply | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa |
Filling volume | 3-60ml | 10-125ml | 10-250ml | 20-500ml | 50-1000ml | 100-2500ml | 200-5000ml |
Filling speed | <30pcs/min | <30pcs/min | <30pcs/min | <20pcs/min | <20pcs/min | <15pcs/min | <12pcs/min |
Material | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 |
Weight | 13kg | 14kg | 16kg | 18kg | 22kg | 28kg | 35kg |
Packing size(mm) | 700*250*300
| 800*250*320
| 1200*300*350 | ||||
Double head:
Model | JF-II-60 | JF-II-125 | JF-II-250 | JF-II-500 | JF-II-1000 | JF-II-2500 | JF-II-5000 |
Air supply | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa |
Filling volume | 3-60ml | 10-125ml | 10-250ml | 20-500ml | 50-1000ml | 100-2500ml | 200-5000ml |
Filling speed | <60pcs/min | <60pcs/min | <60pcs/min | <40pcs/min | <40pcs/min | <30pcs/min | <10pcs/min |
Material | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 |
Weight | 22kg | 24kg | 27kg | 32kg | 36kg | 40kg | 52kg |
Packing size(mm) | 700*420*300
| 800*420*320
| 1200*500*350 | ||||
Photo show of liquid filling machine:
Single head with hopper:
Single head with auto-suction :
Double head with hopper:
Double-head with auto- suction:
Working photo of liquid filling machine:
Flow chart of liquid filling machine:
