Hot Sale and High Effective Sealing Machine

Zhengzhou Kunchi Machinery Equipment Co., Ltd.
Hot Sale and High Effective Sealing Machine thumbnail-1
Hot Sale and High Effective Sealing Machine photo-1
US$ 500 - 5,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Beverage, Commodity, Medical
Packaging Type:
Bottles, Bags, Film, Foil, Pouch
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port of china
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Food, Beverage, Commodity, Medical
Packaging Type Bottles, Bags, Film, Foil, Pouch
Packaging Material Plastic, Metal
Automatic Grade Automatic
Driven Type Electric
Voltage 380V
Power 1400W
Place of Origin Henan, China
Brand Name KUNCHI
Model Number GLF1400
Dimension(L*W*H) 810*390*310mm
Weight 42kg
Certification ISO9001
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Sealing Machine
1.induction sealing
2.plastic bottle foil sealer
3.small size, easy operating

 Hot sale and high effective Sealing Machine

Introduction of sealing machine

Our sealing machine can be totally divided into three parts: Manual electromagnetic Aluminum Foil Sealing Machine,

full-automatic electromagnetic Aluminum Foil Sealing Machine and High Speed Continuous Electromagnetic Aluminum Foil Sealing Machine.

 All of them meet a criterion of GMP.

Characters of sealing machine

1) Type

Manual

GLF-300/ GLF400-1000/ GLF-421K/ GLF-600W/ GLF822KS

Full-automatic

GLF1400/ GLF1400S/ GLF1400N/ GLF1400NS/ GLF1600

High Speed Continuous

GLF1800/ GLF2100Z/ GLF2100L/ GLF3500Z/ GLF3500L

2) Feature



Manual

Manual, both opening and stop of the equipment is automatic, easy operating.

 Efficient sealing, low seal prime cost, heating non-contact, adapting to seal all kinds of plastics bottle and compound plastics bottleneck.





Full-automatic

Rapid sealing, adapting to batch-type production (seal);

The startup and stop is automatic, continuously, and easy operating;

Efficient sealing, excellent quality of sealing;

Low cost;

Heating non-contact, adapting to seal all kinds of plastics bottle and compound plastics bottleneck.

High Speed Continuous

High speed sealing, equip with assembly line, adapting to assembly line big batch-type production (seal).

Can work for 24 hours continuously.

3) Working principle





Manual

Installed with a limited electro circuit in the mainframe in order to avoid damage caused by excessive electric current.

Is a sealed process without contiguous, it makes high heat through electromagnetic induction in a moment,

 that is that aluminum foil is fused on the bunghole, the process is adapt to seal up for safekeeping which most of merchandises without pollution.

Full-automatic

Making use of the principle of electromagnetic. Bottleneck’s aluminum foil makes high heat in a moment,

and then makes it fused on the bottleneck so that the machine could be up to the sealing function.



High Speed Continuous

Bottleneck’s aluminum foil makes high heat in a moment, and then makes it fused on the bottleneck so that the machine could be up to the sealing function.

There are two sets of Main Board and Power Amplifier in it so that it could generate enough electric current and satisfy the rapid sealing.

And equipped with delivering set so as to high speed produce easily.

4) Application



Manual

Mainly for pharmacy, grocery, chemistry, petroleum, agrochemical, cosmetics and other industries. It could be used to seal with aluminum foil for container, containers material quality are plastic bottle, glass bottle and other nonmetal material quality, such as PE, PET, PP, PVC, ABS and so on.



Full-automatic

Good moisture proof, mould proof, forged proof, and prolong the length for preservation.

Mainly working for assembly line, 24 hours continuously.

There is a wide range of uses of it. Mainly for medicine, grocery, oil, daily chemicals, agrochemicals and other industries.







High Speed Continuous

Equip with delivering set so as to high speed produce easily.

Match automatic reject device without aluminum foil bottle, automatic sealing bottle etc.

Efficient sealing (0-240bottles per minute), excellent quality.

Equipment of opening and stop is automatic, continuously, easy operating.

All stainless steel mould forming case, beautiful and dignified, the work of device is stable and reliable.

Heating non-contact, adapting to seal all kinds of plastics bottle and compound plastics bottleneck.

Good moisture proof, mould proof, forged proof, and prolong the length for preservation.

Specification

Type

Capacity(bottle/min)

Sealing Diameter(mm)

Power(w)

Mainframe Size(mm)

Weight(kg)

GLF-300

0-40

15-60

300

310×240×150

3

GLF400-1000

0-40

8-60/60-120/120-300

400-1000

310×240×150

3.5

GLF-421K

0-40

15-60/60-120

400-1000

310×240×150

3.5

GLF-600W

0-40

15-60

600

310×240×150

3

GLF822KS

0-40

8-15/15-60/120-150

400-1000

310×240×150

3.5

GLF1400

0-110

15-70

1400

810×390×310

42

GLF1400S

0-140

10-55

1400

810×390×310

42

GLF1400N

0-110

15-70

1400

805×310×330

40

GLF1400NS

0-140

10-55

1400

805×310×330

40

GLF1600

0-100

30-105/65-150

1600

1005×310×330

46

GLF1800

0-200

15-45/30-60/40-120

1800

420×310×940

55

GLF2100Z

0-200

10-80

2100

1500×640×1150

82

GLF2100L

0-200

10-80

2100

420×310×940

58

GLF3500Z

0-240

20-80

3500

1500×640×2150

100

GLF3500L

0-240

20-80

3500

1420×750×1360

82



 Picture show of sealing machine



 Hot sale and high effective Sealing Machine





Hot sale and high effective Sealing Machine





Hot sale and high effective Sealing Machine





kind Remind:

If you are interested in this machine, please detail your requirements while you are sending your inquiry,

the more, the better, so that we can give you the best recommendation.

Our Service & Cooperation:

1. Pre-sales service:

 ü Sales person, project manager, technology engineer, accountant staff

 ü Professional responsing-team: would be very fastly and exactly to send your offers

 2. Online/sale service

 ü Super and solid quality

 ü Fastly delivery

 ü Standard export package or as your demand

 3. After-sales service

 ü Assistance to build factory

 ü Repairing and maintenance if any problem occur in warranty

 ü Installation and clerks training

 ü Spare and wearing parts for free or with big discount

 ü Any feedback of machines can be told us, and we will try our best to support

 4. Other cooperation service

 ü Technology knowledge share

 ü Factory building advising
