Home > Industrial Equipment & Components > Pump & Vacuum Equipment > Water Pump > Stainlee Steel FSB Fluorine Pump
US$ 0.9 - 1
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
OEM
Theory:
Other, Centrifugal Pump, Centrifugal Pump
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai guangzhou shenzhen HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Stainlee Steel Screw PumpUS$ 100 - 100MOQ: 1 Piece -
Horizontal Split Case Centrifugal PumpUS$ 0.9 - 1MOQ: 1 Piece
-
FSB Fluorine Pump Fluorine Plastic Chemical PumpUS$ 0.9 - 1MOQ: 1 Piece
-
Self-aligning Ball Bearing 1214 for Cement MachineryUS$ 0.5 - 0.5MOQ: 1 Piece
-
Self-aligning Ball Bearing 1213 for Sugar Pressing EquipmentUS$ 0.5 - 0.5MOQ: 1 Piece
Place of Origin
Jiangsu, China
Brand Name
OEM
Theory
Other, Centrifugal Pump, Centrifugal Pump
Structure
Gear Pump
Usage
Other, Air Pump, Chemical
Power
Other, Electric, Electric
Standard or Nonstandard
Nonstandard
Fuel
Diesel
Pressure
Other, High Pressure, Middle pressure
Application
Maritime
Product Description
1. Introduction:
1. FSB fluorine plastic chemical pump is reasonable design, compact structure, reliable performance, easy to use and saving energy.
2. Applied to convey acid, oxidant, corrosive medium (forbid to transit medium likely to crystallize) with physical property similar to water.
3. Wet parts are made of fluorine plastic alloy through reasonable design, mold pressing, machining, with advantages of strong corrosion resistance ability, high mechanical strength, non aging, no toxin decomposed.
4. It is widely used in the fields of chemical industry, petrol, medicine, pesticide, dye, smelting, paper making, plating, and food, etc.
2. Product details:
| Working Principle: | Centrifugal |
| Main applications: | Chemical |
| Driver: | Electric motor |
| Power Specs: | 380/415V 3phase;50hz/60hz |
| Max.permissible fluid temperature: | 150°C(302°F) |
| Type of connection: | Flange |
| Installation position: | Horizontal |
| Casing parts material: | Fluorine plastic |
| Shaft seal type: | Mechanical seal |
| Free passage: | 1 mm |
| Maximum drive rating: | 75KW(100HP) |
| Maximum caliber: | 200mm(8inch) |
| Maximum discharge-side pressure: | 0.8MPa(8bar) |
| Maximum head: | 80m(262.4ft) |
| Flow rate range: | 1.5-400m3/h(6.6-1760US.GPM) |
3. Performance data:
| Model | Capacity | Head | Inlet | Outlet | Power | Speed | Suction | Efficiency |
| (m3/h) | (m) | (mm) | (mm) | (KW) | (r/min) | (m) | (%) | |
| 25FSB-10L | 1.5 | 10 | 25 | 20 | 2.2 | 2900 | 6 | 29 |
| 25FSB-18L | 3.6 | 18 | 25 | 20 | 2.2 | 2900 | 6 | 27 |
| 40FSB-15L | 10 | 15 | 40 | 32 | 3 | 2900 | 6 | 40 |
| 40FSB-20L | 10 | 20 | 40 | 32 | 3 | 2900 | 6 | 42 |
| 40FSB-30L | 10 | 30 | 40 | 32 | 3 | 2900 | 6 | 38 |
| 40FSB-40L | 10 | 40 | 40 | 32 | 4 | 2900 | 5.5 | 35 |
| 40FSB-50L | 10 | 50 | 40 | 32 | 5.5 | 2900 | 5 | 33 |
| 50FSB-20L | 15 | 20 | 50 | 40 | 4 | 2900 | 6 | 51 |
| 50FSB-25L | 15 | 25 | 50 | 40 | 4 | 2900 | 6 | 49 |
| 50FSB-30L | 15 | 30 | 50 | 40 | 4 | 2900 | 6 | 44.5 |
| 50FSB-40L | 15 | 40 | 50 | 32 | 5.5 | 2900 | 5.5 | 35 |
| 50FSB-50L | 15 | 50 | 50 | 32 | 7.5 | 2900 | 5.5 | 33 |
| 65FSB-32L | 29 | 32 | 65 | 50 | 5.5 | 2900 | 6 | 57 |
| 65FSB-40L | 29 | 40 | 65 | 40 | 7.5 | 2900 | 5.5 | 53 |
| 65FSB-50L | 29 | 50 | 65 | 40 | 11 | 2900 | 5.5 | 46 |
| 80FSB-20L | 50 | 20 | 80 | 65 | 7.5 | 2900 | 6 | 69 |
| 80FSB-30L | 50 | 30 | 80 | 65 | 7.5 | 2900 | 5.5 | 64 |
| 80FSB-34L | 50 | 34 | 80 | 65 | 11 | 2900 | 5.5 | 64 |
| 80FSB-38L | 50 | 38 | 80 | 50 | 11 | 2900 | 5.5 | 60 |
| 80FSB-50L | 50 | 50 | 80 | 50 | 15 | 2900 | 6 | 53 |
| 80FSB-80L | 50 | 80 | 80 | 50 | 22 | 2900 | 5.5 | 36 |
| 100FSB-32L | 100 | 32 | 100 | 80 | 18.5 | 2900 | 5.5 | 70 |
| 100FSB-40L | 100 | 40 | 100 | 80 | 22 | 2900 | 5.5 | 70 |
| 100FSB-50L | 100 | 50 | 100 | 65 | 30 | 2900 | 5.5 | 62 |
| 125FSB-32L | 200 | 32 | 125 | 80 | 30 | 2900 | 5.5 | 72 |
| 125FSB-50L | 200 | 50 | 125 | 100 | 45 | 2900 | 5.5 | 64 |
Packaging & Shipping
Packaging Details:
Plywood case for normal pumps and machines, plate for heavy pumps and machines.
Delivery Detail:
Shipped in 3 days after payment
