Breif introduction of boimass burner.
biomass burner use boimass pellets, wood chips etc as fuel in suspensionmboiling, half gasification pyrolysis combustion way. through radiation, convection heat transfer to thermal equipment. it make up of automatic feeding system, fan blower, burning room, bocca, ignition system. the ideal way for fossil fuel change to clean fuel. widely used in food processing, printing, coating, baking varnish, heating, bath industries.
Features of Boimass burner:
1: Boiling semi-gasification combustion Gache line with the wind swirling design
2: Heat load adjustment range
3: Staged combustion technology using low temperature,
4: It running under micro-pressure state, no tempering or flame-lifting.
Advantage of boimass burner
1: Energy-efficient: recyling biomass energy as fuel
2: High thermal efficiency: the pellet fuel can burn completely, up to 98% burning rate.
3: Easy operation: adopt automatic feeding system, easy to operate
4: Fiber reinforced castables instead brick as heat protection parts,avoid broken
Technical parameters of boimass burner
Model |
Heat power |
Motor power |
Pellet consumption |
dimension |
Weight |
YGF-20-1(LR) |
20 |
0.75 |
50 |
1900*910*1710 |
0.6 |
YGF-30-1(LR) |
30 |
0.75 |
75 |
1920*925*1750 |
0.7 |
YGF-45-1(LR) |
45 |
1.15 |
115 |
1830*1100*2130 |
1 |
YGF-60-1(LR) |
60 |
1.9 |
150 |
2340*980*2180 |
1.6 |
YGF-60-1(LR) |
60 |
1.9 |
150 |
2340*980*2180 |
1.6 |
YGF-90-1(LR) |
90 |
3.1 |
225 |
2790*1190*2400 |
2.2 |
YGF-120-1(LR) |
120 |
3.7 |
300 |
2900*1300*2420 |
3 |
YGF-180-1(LR) |
180 |
5.25 |
450 |
3180*1490*2400 |
3.8 |
YGF-240-1(LR) |
240 |
8.45 |
600 |
3250*1660*3520 |
4.8 |
YGF-300-1(LR) |
300 |
10.45 |
750 |
3800*1950*3130 |
8 |
YGF-360-1(LR) |
360 |
10.45 |
900 |
3950*2100*3270 |
9 |
YGF-420-1(LR) |
420 |
10.8 |
1050 |
4050*2200*3370 |
10 |
YGF-480-1(LR) |
480 |
10.8 |
1200 |
4200*2350*3490 |
11 |
Company information:
Shandong Rotex mechinary co., ltd, an professional manufacturer in boimass fuel machinary for 8 years, with main products: wood pellet machine, feed pellet machine, drum wood chipper and hammer mill, rotary dryer, cooling equipment and other auxiliary equipments.
Exhibition
Our team
Our Service:
Pre-service: design suitable plan for you according your material shape, size and moisture content. with less cost but biggest efficiency.
During-purchase service: control quality, delivery intime
After service: if you ask, technicians will be sent to your place to guide installation and degug and train your operator.
Any interest, pls contact me. BEST SOLUTION will be supplied as per your request!
