Specifications
1. High Performance2. High Capacity
3. Professional Manufacture
4. Export More than 30 Countrys
Rotary Dryer
Skype: zkbm1998
Detail Description of Rotary Dryer:
1. Structure: The rotary dryer mainly consists of revolved body, raise material board, transmission device,
support device and seal ring etc.
2. Advantages: The rotary dryer has the advantages of reasonable structure, excellent manufacture, high
output, low energy consumption, convenient operation and so on.
3. Application materials: The rotary dryer is applicable for particle materials, and is also applicable for paste
and viscous materials which are mingled with particle materials, or materials whose water content is high.
This rotary dryer can dry many kinds of materials which contain moisture, such as gypsum,sand ,coal, coal
slurry, slag, industrial waste, and clay stone. Rotary dryer are widely used in building materials, metallurgy,
and chemical industry.
Rotary Dryer Work Principle:
Conveyed from the feed screw directly into the dryer drum, raised by the drum wall panels repeatedly,
and scattered by the crushing blow dispersion devices, materials and the negative high temp media are
combined sufficiently to complete heat and mass transfer process. Because of the influence of the roller
angle and the induced draft fan, the material move slowly from the inlet side to the outlet side , then they
are discharged by the airflow in the outlet side, after further drying by the pipeline, the material enter into
the dust catcher, finally shut out from the air seal machinery.
Main Technical Parameters:
Model | Gradient (°) | Speed (R/min) | Volume (m³ ) | Power (kw) | Capacity (t/h) | Weight (t) |
Φ0.6×8m
| 3-5 | 8 | 2.26 | 4 | 1-3 | 2.9 |
Φ0.8×10 m
| 3-5 | 7.2 | 5.02 | 4 | 4-6 | 4.5 |
Φ1.0×10 m
| 3-5 | 6.73 | 7.85 | 5.5 | 5-8 | 5.6 |
Φ1.2×12 m
| 3-5 | 5.8 | 13.31 | 11 | 8-12 | 14.8 |
Φ1.5×12 m
| 3-5 | 4.8 | 21.2 | 15 | 10-15 | 17.8 |
Φ1.8×14 m
| 3-5 | 3.2 | 48.22 | 30 | 12-18 | 27 |
Φ2.2×18 m | 3-5 | 3 | 70.43 | 37 | 15-20 | 53.8 |
Φ2.4×20 m
| 3-5 | 2.83 | 90.43 | 45 | 20-25 | 60 |
Φ2.8×24 m
| 3-5 | 2.59 | 147.8 | 75 | 25-30 | 67 |
Φ3×20 m
| 3-5 | 1.5-5 | 141.3 | 55 | 25-35 | 78 |
Φ3×25 m
| 3-5 | 1.5-5 | 176.6 | 75 | 32-40 | 104 |
