Specifications
SG series hammer mill:1.CE,SGS,ISO approved
2.CNC system, heat treatment
3.high output, low consumption
Hot selling JINKUN SG series hammer mill
We produce biomass pellet making line machines, such as wood logs debarking machine, wood logs splitter,
wood sawdust making machine ,wood chipper, hammer mill, grass/straw cutter , straw bale crusher, pellet machine and briquette machine, dryer and cooler, screener, mixer , biomass pellet boiler, pellet packing machine and all conveyors e. c. t. for wood hammer mill details, as below :
1 SG series multifunctional Hammer Mill is the most ideal grinding equipment for all kinds of wood pieces,
wood shavings,grass,straw,stalk,corn,weeds,soybean and so on.it adpopts water cooling structure inside,
avoiding the damage to spare parts due to long time working friction .except biomass, it also can crush animal feed
materials such as soybean, maize, cereal and fertlizer materials from animal manure, chemical e.c.t which is mainly
used in wood factory,foddor factory, cultivation factory, organic fertilizer factory, and so on.
2. we will install fit hole screener at theSG series multifunctional Hammer Mill bottom according to materials moisture
and Characteristics .if raw materials were high humidity , then we will send 10-20mm hole screener even no screener at the bottom, if dry, then will install 2-4mm hole screener, which means will outlet smaller than 2mm fine powder.
3. TheSG series multifunctional Hammer Mill spare parts hammers and screener are made by our CNC systems,
through high technical heat treatment, standing out from other suppliers is that we could ensure its high precision and
durable working efficiency .
4. SG series multifunctional Hammer Mill works connect with air fan and cyclone , crushed powder will outlet from
cyclone bottom, which is very environmental protection and easy to collect powder.
5. SG series multifunctional Hammer Mill is hot selling 5000sets per year , we have big discount for old customer,
for any questions, please feel free to ask
hammer mill Technical Parameter:
Model |
Capacity (T/H) |
Power (KW) |
Weight(T) |
Size(mm) |
Hammer pieces |
JK40 |
0.2-0.5 |
7.5 |
0.27 |
1310*800*1070 |
12 |
JK50 |
0.6-0.8 |
15 |
0.45 |
1380*800*1010 |
16 |
JK65*27 |
0.8-1.5 |
22 |
1.1 |
1500*1000*1100 |
24 |
JK65*55 |
1-2 |
37-45 |
1.5 |
1700*1000*1100 |
48 |
JK65*75 |
2-3 |
55-75 |
1.9 |
2100*1000*1100 |
72 |
JK65*100 |
3-4 |
90-110 |
2.3 |
2400*1000*1100 |
90 |
JK130*55 |
5-6 |
130-160 |
5.3 |
2800*1620*2100 |
80 |
JK130*100 |
7-8 |
160-220 |
6.8 |
3020*1620*2170 |
160 |
