Homemade wood pellet burner for sale
1,Product Introduction
Biomass pellet burner, a new design concept, and production of a fifth-generation burner, so that all burning biomass particles to find a solution.
Furnace combustion does not afraid slagging, break the limit that the pellet burner just can use the wood pellet as fuel. The fifth-generation machine suitable for all biomass combustion particles as fuel.
The unique design of structure, part of the water vapor can burn involved in decomposition, so that energy consumption is minimized.
Intelligent design, broadband frequency smokeless combustion, the fuel has been most fully combustion.
Range of application.
Biomass pellet burner is widely used in boilers, die-casting machines, industrial furnaces, incinerators, smelting furnace, kitchen equipment, drying equipment, food drying equipment, ironing equipment, painting equipment, road construction machinery and equipment, industrial annealing furnace, asphalt heating equipment and other energy industries.
2, Technic Data
| Model | Rated Output | Burning Consumption | Voltage | Power | Machine Size | Discharge Mouth mm | Reference | Related Stove | Related Dryer | |
| KW | KG | V | KW | L*W*H mm | Diameter | Height(ground to mouth center) | Weight Kg | Evaporation | Evaporation | |
| T/H | T/H.Efficiency0.7 | |||||||||
| BC60 | 60 | 13 | 220 | 0.8 | 1200*500*1500 | 160 | 600 | 500 | 0.085714286 | 0.06 |
| BC120 | 120 | 27 | 220 | 0.9 | 1200*500*1500 | 160 | 600 | 600 | 0.171428571 | 0.12 |
| BC300 | 300 | 67 | 220 | 1.5 | 1400*540*1500 | 200 | 800 | 750 | 0.428571429 | 0.3 |
| BC500 | 500 | 111 | 220 | 1.5 | 1400*540*1500 | 200 | 800 | 1000 | 0.714285714 | 0.5 |
| BC800 | 800 | 178 | 220 | 2.2 | 1800*600*1500 | 380 | 800 | 1200 | 1.142857143 | 0.8 |
| BC1200 | 1200 | 267 | 380 | 2.2 | 1800*600*1500 | 380 | 800 | 1200 | 1.714285714 | 1.2 |
| BC1600 | 1600 | 356 | 380 | 3.2 | 2000*1000*1500 | 400 | 850 | 1400 | 2.285714286 | 1.6 |
| BC2400 | 2400 | 533 | 380 | 4.2 | 2000*1000*1500 | 500 | 851 | 1700 | 3.428571429 | 2.4 |
| BC3000 | 3000 | 667 | 380 | 4.5 | 2600*1000*1500 | 670 | 900 | 2000 | 4.285714286 | 3 |
| BC4000 | 4000 | 889 | 380 | 8 | 2600*1200*1550 | 670 | 900 | 2400 | 5.714285714 | 4 |
| BC5000 | 5000 | 1111 | 380 | 9 | 2600*1200*1550 | 670 | 1100 | 2800 | 7.142857143 | 5 |
| BC6000 | 6000 | 1333 | 380 | 11.5 | 2800*1300*1600 | 700 | 1100 | 3200 | 8.571428571 | 6 |
| BC7000 | 7000 | 1556 | 380 | 11.5 | 3000*1500*1700 | 800 | 1100 | 4000 | 10 | 7 |
| BC8000 | 8000 | 1778 | 380 | 16 | 3000*1500*1700 | 800 | 1200 | 4400 | 11.42857143 | 8 |
3,Workshop Production
4,Contact
