2014 Hot sales sand screening machine with good screenig effect
Sand screening machine ---Product Description :
Sand screening is a kind of equipment applied more widely, mainly composed of vibrator, screen box, bearing or suspension, transmission and so on. It uses the strong vibratory force of itselves’ running to make the material do vibrating and throwing sports on the screen so as to achieve the using effect of screening. It can adjust the size of the screen according to the particle size of materials, thus meet the screen demand of different materials.
Sand screening machine---Structure:
Sand screening machine---Working principle:
Sand screening machine ---Applications:
It has widely applicable scope, and can be used with different equipments. Now it is widely used in sand, construction, building materials, pharmaceutical industry, agriculture, food and other various industries. And its using effect can achieve screening precision of different industries.
Sand screening machine---Advantages:
1 Adjustable the exciting force produced by device’s running.
2 Simple structure
3 Less screen aperture’s blocking phenomenon, high efficiency
4 High usability of transmission
5 Special shockproof device to ensure long using life
6 Large capacity
The screen of sand screening machine:
Sand screening machine---Detail parameters:
| Model | Layer | Sieve Area | Mesh Size | Maximum Feeding Size | Capacity | Vibration Power | Power | Screen Inclination | Sieve Size | Weight | Overall size |
| (m2) | (mm) | (mm) | (m3/h) | (r/min) | (kw) | (Angle) | (mm) | (kg) | (L×W×H)(mm) | ||
| 2YK1225 | 2 | 6 | 4-50 | 400 | 8-60 | 800-970 | 5.5 | 20 | 1200×2500 | 3500 | 2930×1860×870 |
| 3YK1535 | 3 | 15.75 | 5-50 | 400 | 21-125 | 800-970 | 11 | 20 | 1500×3500 | 6700 | 4360×2210×1610 |
| 4YK1545 | 4 | 27 | 5-50 | 400 | 22-155 | 800-970 | 18.5 | 20 | 1500×4500 | 7800 | 5930×2210×2060 |
| 4YK1548 | 4 | 28.8 | 5-50 | 400 | 22.5-162 | 800-970 | 18.5 | 20 | 1500×4800 | 8700 | 6230×2210×2060 |
| 3YK1848 | 3 | 25.92 | 5-80 | 400 | 32-276 | 750 | 18.5 | 20 | 1800×4800 | 9600 | 5660×2550×1780 |
| 4YK1854 | 4 | 34.54 | 5-80 | 400 | 32-285 | 750 | 22 | 20 | 1800×4800 | 11100 | 6290×2550×2160 |
| 4YK1854 | 4 | 38.88 | 5-80 | 400 | 32-336 | 800-970 | 30 | 20 | 1800×5400 | 12840 | 6830×2550×2160 |
| 3YK2160 | 3 | 37.8 | 5-100 | 400 | 50-475 | 970 | 30 | 20 | 2100×2600 | 12800 | 7030×2840×1910 |
| 4YK2160 | 4 | 50.4 | 5-100 | 400 | 50-497 | 970 | 37 | 20 | 2100×2600 | 14800 | 7300×2840×2380 |
| 3YK2460 | 3 | 43.2 | 5-100 | 400 | 70-620 | 970 | 37 | 20 | 2400×6000 | 17600 | 7300×3140×1910 |
| 4YK2460 | 4 | 57.6 | 5-100 | 400 | 80-680 | 970 | 45 | 20 | 2400×6000 | 19600 | 7600×3140×2380 |
Supply perfect after-sale service:
Company is responsible for one package service including buyers’ process design, on-site construction guidance, equipment installation and debugging, training technical persons and operators. Three Guarantees, one year warranty and long-term supply of components.
About Hongyun:
Hongyun is a modern enterprise which makes scientific research, production and sale integration.The machinery factory has 20 years of production experience and performance in the mineral processing equipment and baking-free brick equipment industry, which changes from state-owned enterprise to private enterprise. We have many skilled technical persons and experienced after-sales service team, so we can offer customers a full of crushing screening from monomer to solutions. And we can provide customers with professional technology support, reliable supply of spare parts and high quality of after-sales service.
Our technical personsl and customers
We also have other products such as crusher, dryer and others. If you want to know more about our products, please contact us timely! we will warmly welcome!
