Mini corn dryer application:
Mini corn dryer is mainly used for rice, corn, wheat, sorghum, soybean, rapeseed and other granular food and economic crop through low temperature air to dry.
Mini corn dryer structure characteristics:
Inside of the mini corn dryer, the hot blast stove can be used separately drying chili, cowpea, honeysuckle, vegetables and other sticks or block materials. In a word: multi-usage.
Mini corn dryer working principle:
1, Spent grain dryer adopts rotary heating device, it can output enough hot air in a short time and kill eggs though high temperature.
2, Spent grain dryer also adopts digitization control and instrumentation to control drying box’s temperature to avoid appearing discoloring and metamorphic phenomenon.
3, Spent grain dryer cabinet is made of metal aluminum plate and silica gel cotton insulation layer to reduce energy consumption effectively.
4, Cyclotron system can reach the purpose of air circulation, humidification and heating in the drying box.
Performance characteristics:
1,Use circulation drying method
2,No pollution
3,Drying fast
4,Effect good
| Model | HY-1.2-8 | HY-1.6-8 | HY-2-8 | HY-2-10 | |
| Number of element | 4 | 4 | 4 | 5 | |
| Belt width (m) | 1.2 | 1.6 | 2 | ||
| Drying section length (m) | 8 | 8 | 8 | 10 | |
| Spreading thickness (mm) | 10-80 | ||||
| Operation temperature(℃) | 50-120 | ||||
| Steam pressure(Mpa) | 0.2-0.6 | ||||
| Steam consumption(Kg/h) | 120-130 | 150-375 | 180-500 | 225-600 | |
| Heat transfer area(m2) | 272 | 352 | 448 | 560 | |
| Drying time(h) | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.5 | |
| Drying intensity(Kg /h ) | 60-160 | 75-220 | 100-260 | 120-300 | |
| The fan number | 5 | 5 | 5 | 6 | |
| Total power of the device(kw) | 8.5 | 15.5 | 22 | 27 | |
| Dimension | Length(m) | 2 | 2.3 | 2.3 | 2.3 |
| Width(m) | 2 | 2.3 | 2.5 | 2.9 | |
| Height(m) | 7.2 | 9 | 12 | 12 | |
| Gross weight(T) | 5 | 6 | 8 | 12 | |
