260 workers, 25000 square meters non-dust workshop, 12 years experience, 3 years' vendor of Wal-mart, ISO, CE & FDA certificated, two hours reach Shanghai port, this is how we keep superior quality and competitive offers for global valued customers
1, High speed and high precision.
2, man-machine dialogue operation interface.
3, setting of bags length can simple and reliable adjustments in a wide-area.
4, photoelectric automatic calibration within three bags.
5, double variable frequency drive, stable and reliable running.
6, roller suppoted by high temperature bearing, perfect sealing, free maintenance, low noise
Packing Speed | 20-120 Bottles/min | |
Capacity Range | 1-50ml | |
Mechanical Power | 3.8KW/AC 380V | |
Mechanical Dimensions | L3200mm*W800mm*H1500mm | |
Net Weight | 400Kg | |
Optional Device | Product conveying belt, Voltage regulator, Air compressor | |
In our machine, there are lots of electronic parts, some of them come from chinese best manufacturers and some from japan, german. They have different function to make the whole machine running well, we making a simple list to show these parts.
Touch screen: | WeinView touch screen |
PLC Module: | Delta PLC |
AC contactor: | DELIXI |
Relays: | Omron |
Color logo recognition sensor: | BALEFU |
Angle encoder: | Seiko |
Circuit protector: | DELIXI |
Main Motor: | YUQIU |
Type 80 vertical gear reducer: | YUQIU |
Type 50 horizontal gear reducer: | YUQIU |
Solid state relays: | Tianhao |
• Work automatically: Measuring--making bag--coding (option)--filling--sealing --cutting
• Computer control system, photoelectric tracking
• Machine body is full of stainless steel
• Can install color ribbon printer for 1-3 lines
• Has fault display system, easy to operate and maintain
• All stainless steel cover meets to GMP standard
• Automatic adjustment of pouch size and filling range
• Photocell controller is easy to manipulate
• The horizontal sealing uses high temperature resistant bearing which will ensure the continuous operation of the machine without filling the oil regularly
• The operation facility is controlled by American intel computer, all function is displayed with digital screen
• Minimum sealing temperature variation employs PID temperature, the tolerance is controlled by ±2%
Our machine can be applied to following scope & products, include Food, Medicine, Pesticide or some other related liquid materials (As shown)
We have a group of Seasoned workers, their average age is 40 years old, and the chief engineer is Chinese first batch of personnel that engaged in design and manufacture of packaging machinery industry, our company also spends resources for the cultivation of young engineers. With them, we can promise you the high quality and best after-sale service. All our processing flows comply with related standards to ensure our products qualified leave factory, there are some pictures show the processing
