HT-RG6 semi automatic multifunction high speed pneumatic soft tube filling machine
HT - RG6 series soft tube filling machine adopts advanced PLC and touch screen control system, intuitive, convenient and reliable.This machine structure is compact, manual install tube, using photoelectric to finish automatic precise positioning, automatic detection, realize intelligentize filling work.The machine shell adopts 304 stainless steel, reasonable design, simple operation, convenient maintenance, mainly used in all kinds of viscous or pasty fluid of cosmetics, daily chemical, pharmaceutical and other industries.The machine can replace filling part according to different hoses or bottles, suitable for filling most alien hose or special-shaped bottle.
Characteristic
1, High speed and high precision.
2, man-machine dialogue operation interface.
3, photoelectric automatic calibration within three bottle.
5, double variable frequency drive, stable and reliable running.
Application scope
All kinds of paste type cosmetics, skin care products or other similar materials.
.
Technical parameters
Applicable specifications |
1-150ml |
Production capacity |
10-60bottles/min/row |
Filling accuracy |
≤±1% |
The power supply |
380V/50HZ |
Power |
1.0KW |
Screw cap rate |
≥99% |
Air supply |
4 m3/h 0.6-0.8Mpa |
Net weight |
300KG |
Dimensions |
3200*800*1550mm |
Electrical control system
Touch screen: |
WeinView touch screen |
PLC Module: |
Delta PLC |
AC contactor: |
DELIXI |
Relays: |
Omron |
Color logo recognition sensor: |
BALEFU |
Angle encoder: |
Seiko |
Circuit protector: |
DELIXI |
Main Motor: |
YUQIU |
Solid state relays: |
Tianhao |
Partners
Processing
After Sales Service
·Find our products through or http://hi-techmachinery.en.china.cn
· One year warranty for the whole machine
· Free equipment installation and debugging
·After one year, we can help you to maintain the machine and the accessories are provided omle one the cost price
·Every 3 years, we can help to overhaul the machine freely (labor)
·We can provide internship service and help you train the operator and machunic
·Free production technology and process configuration
