HBS-500 2015 Gaode Huge Scrap Alloy Engine in Suitable Size

Name: HBS-500 2015 Gaode Huge Scrap Alloy Engine in Suitable Size
Brand: gaode
SKU: 141042156
Availability: InStock

Jiangsu Gaode Hydraulic Machinery Co., Ltd.

US$ 250,000 - 260,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Jiangsu, China

Brand Name:

gaode

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Jiangsu, China

Brand Name gaode

Model Number HBS-500

Voltage 380

Rated Power 110KW

Dimension(L*W*H) none

Weight none

Certification ISO9001:2000

Warranty 6 months

After-sales Service Provided Engineers available to service machinery overseas

No.	baler &shear Technical Specification					Remark
1	Press Box Size(LWH)			50001600900mm
2	Bale Size(LWH)			700*500mm
3	Hydraulic System Pressure			25 MPa
4	Total Motor			110KW
5	Power			380V/3PH,50Hz
6	Blade Length			800mm
7	Shearing Frequency (times/min)			3-5 time/min
8	Capacity(Ton/Hour)			4-12
9	Max Cutting Force (material Tensile Strength no more than 440MPa)			Round TeelΦ120mm
				Billet 110*110mm
				Steel Plate 50*600mm
10	Motor	Model	Y200L₂-6	Nominal Power	55KW
		Nominal Speed	970rmp	Quantity	2 pieces
11	Hydraulic Pump	Model	250YCY14-1B	Nominal Pressure	31.5MPa
		Nominal Outflow	250ml/r	Quantity	2 Pieces
12	Equipment Outline Dimension			1130028003500(Flank Expansion)		LWH
				1130022003500mm(Flank Collapsed)		LWH
13	Floor Space			14000*4000mm		L*W
14	Control System			PLC Automatic Control
15	Cooling System			Oil - steam heat exchanger
