250Tons Hydraulic Scrap Copper Compress Metal Baler Machine

250Tons Hydraulic Scrap Copper Compress Metal Baler Machine thumbnail-1
250Tons Hydraulic Scrap Copper Compress Metal Baler Machine photo-1
US$ 38,000 - 38,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New, Hot sale
Automatic Grade:
Semi-Automatic
Usage:
Metal Forming Machine
Contact Supplier Request Quote Chat Now
Jiangsu Gaode Hydraulic Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai for 250Tons Hydraulic Scrap Copper Compress Metal Baler Machine
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Automatic Grade Semi-Automatic
Usage Metal Forming Machine
Place of Origin Jiangsu, China
Brand Name gaode
Model Number HC81/T-2500
Voltage Customized
Power(W) 60KW
Dimension(L*W*H) 5300x2600x1200mm
Weight 24T
Certification CQC;CE, ISO9001: 2008
Warranty 6 Months, 180Days
After-sales Service Provided Engineers available to service machinery overseas



Product Description



New 250Tons Hydraulic Scrap Copper Compress Metal Baler Machine

250Tons Hydraulic Scrap Copper Compress Metal Baler Machine

250Tons Hydraulic Scrap Copper Compress Metal Baler Machine

 Remarks: Turn-out, hand valve control.





 Technical Specifications Of 250Tons Hydraulic Scrap Copper Compress Metal Baler Machine:

Model Nominal Force(KN) Press box size L*W*H(MM) Bale size( W*H)(MM) Bale Density(KG/M3) Capacity(KG/H) Cycle Time(S) Power(KW) Bale Discharging/Operation
HC81/F-630 630 1000X600X500 (180-250) X190X190 ≥1800 500-1000 90 7.5 Turn-out, hand valve control
HC81/F-1000 1000 1000X600X500 (200-300)X200X200/octagon ≥1800 1000-1200 120 11
HC81/F-1250 1250 1200X700X600       1150X700X600 230X230 Or 300X300/octagon (150-400)X250X250 ≥1800 1000-1500 120 11Or15
HC81/T1250A HC81/T1250B 1250 1200X700X600       1150X700X600 230X230 Or 300X300/octagon   (150-400)X250X250 ≥1800 1000-1500 80 18.5 Push-out, manual valve control or PLC control
HC81/Q-1350 1350 1100X600X600 1300X600X600 (50-300)X600X240 ≥1800 1800-2500 150 18.5 Or 22 Forward-out,manual valve control
HC81-2000Y 1500 900 X 550 X 500   150X500 ≥2000 500-800 120 22 Manual discharging, Electric control
HC81/F-1600 1600 1600X1000 X 800 (400-600)X350X350   (400-600)X400X400 ≥1800 2000-3000 150 22 Turn-out, hand valve control
HC81/T-1600A 1600 1600X1000 X 800 (400-600)X350X350   (400-600)X400X400 /octagon  ≥1800 2000-3000 150 22 Push-out, manual valve control
HC81/T-1600B 1600 1600 X1200 X800 (400-600)X350X350   (400-600)X400X400  ≥1800 2000-3000 160 30
HC81/F-2000 2000 1600X1200X800 (400-700)X400X400 ≥1800 2500-4000 160 30 Or 37 Turn-out, hand valve control
HC81/T-2000A 2000 1600X1200X800 (400-700)X400X400 ≥1800 2500-4000 160 30 Or 37 Push-out, manual valve control or PLC control
HC81/T-2000B 2000 1800X1400X900 (400-700)X400X400 ≥1800 2500-4500 160 30 Or 37
HC81/T-2500A 2500 2000X1400X900 (400-700)X500X500 ≥1800 3500-5000 160 44 Or 60 Push-out, manual valve control
HC81/T-2500B 2500 2000X1400X1200 (450-800)X600X600 ≥1800 3500-5000 160 60
HC81/F-2500 2500 2000X1400X900 (400-700)X500X500 ≥1800 3500-5000 160 44 Turn-out, hand valve control
HC81/F-3150 3150 2000X1400X1200 (450-750)X600X600 ≥1800 3500-5000 160 60
HC81/T-3150A 3150 2000X1400X1200 (450-700)X600X600 ≥1800 3500-5000 160 60 Push-out, manual valve control or PLC control
HC81/T-3150B 3150 2600X1750X1200 (450-800)X650X650 ≥1800 4000-5000 160 90
HC81/T-4000A 4000 2600X1750X1200 (500-1000)X650X650 ≥1800 5000-6500 160 90
HC81/T-4000B 4000 3000X2000X1200 (600-1100)X600X700 ≥1800 6000-8500 160 110
HC81/T-5000 5000 5000X2000X1200 (600-1100)X600X700 ≥1800 9000-11500 180 110



Prodcution Flow:









Company Information

GAODE Hydraulic Machinery has been a trusted name in the waste recycling equipment industry for over a decade as a dedicated Chinese manufacturer of scrap metal recycling equipment, our flagship products includethe shear baler, scrap baler, scrap shear, and recycling crane.

In addition to scrap metal processing equipment, we also supply horizontal baler and vertical baler for compacting plastic, paper, cardboard, straw, textile and more types of wastes.

Our company was first inaugurated in 2003.We have combined advanced production and testing instruments with state-of-the art manufacturing techniques to yield outstanding product quality.

Our GAODE brand has received critical acclaim both domestically and overseas. As a trusted waste recycling equipment manufacturer, we have successfully passed the certification of both the TUV and the ISO9001 Quality Management System. We are currently in the process of obtaining the approval of European standards such as CE and UL.



Certificates Of 250Tons Hydraulic Scrap Copper Compress Metal Baler Machine:





Packaging & Shipping



 Our exhibition

Welcome to our company





Our Services

6months guarantee for whole machine

24hours technical support by email

Calling or door to door service

User manual and detailed video



Contact Information

Ms. Apple Zhang

Sales representative

Jiangsu Gaode Hydraulic Machinery Co.,Ltd---China factory

Add: No. 691 Chengshan Road, Jiangyin City, Jiangsu Province.

Mobil/What's App : +86-15906169741 (24/7)

Tel: 86-510-86996082

Fax: 86-510-86993993

Skype: zhangguoping520

QQ: 445228997





FAQ

Q1:Can I add my logo on the machines?

A: Yes,OEM and ODM are available for us.

      But you should send us the Trademark authorization letter.

Q2:How can i get the after-service?

 A: We will send you the spare parts by free if the problems caused by us.

     If it is the men-made problems,we also send the spare parts,but you should pay.

Q3:Do you have inspection procedures for machines?

A:100% self-inspection before packing

Q4:Can I have a visit to your factory before the order?

A:Sure,welcome to visit our factory.
    Here is our factory address:No.691, Chengshan Road, Jiangyin City, Jiangsu Province, China.

Q5: Can we order one set machine?

 A:Yes, you can.
