| Automatic Grade Small Aluminum Can Baler for sale |
No. | Technical Parameter | Remarks | ||||||
1 | Main Cylinder | Model | YG280/200-1300 | 1set | ||||
Nominal force | 1600KN | Stroke | 1300MM |
| ||||
2 | Side Cylinder | Model | YG250/180-1250 | 1set | ||||
Nominal force | 1250KN | Stroke | 1250MM |
| ||||
3 | Lid Cylinder | Model | YG180/120-1175 | 1set | ||||
Nominal force | 630KN | Stroke | 1175MM |
| ||||
4 | Small door Cylinder | Model | YG125/80-450 | 1set | ||||
Nominal force | 125KN | Stroke | 450MM |
| ||||
5 | Press box size (L*W*H) (MM) | 1600*1000*800 |
| |||||
6 | Bale size (L*W*H) (MM) | 400*400 |
| |||||
7 | Working pressure (Mpa) | 21.5 (small door system6Mpa) |
| |||||
8 | Bale density (Kg/m3) | ≥1800(Fe) |
| |||||
9 | Single cycle | ≥100S |
| |||||
10 | Motor | Model | Y200L2-6 | Power | 22KW |
| ||
Speed | 970r/min | Quantity | 1set |
| ||||
12 | Pump | Model | 160YCY14-1B | Pressure | 31.5Mpa |
| ||
Outflow | 160ml/r | Quantity | 1set | |||||
Applications:
HC81 series of hydraulic metal balers are applicable in steel plants, recycling companies, ferrous &non-ferrous smelting industry to press metal scraps (steel, copper, aluminum, stainless steel, discarded automobiles) into acceptable furnace charges (shapes: cuboid, cylinder or octagon), so as to reduce cost of transportation, to increase speed of furnace charging.
Features:
1, Hydraulic drive for all machine types, manual valve control or PLC control .
2, Bale-discharging:" turn-out"," push-out "," forward-out" or manual discharging.
3, No footing bolts needed in installation ; diesel engine can be equipped for power.
4, Baling force 10 grades from 63 to 400 tons ; productivity from 4 to 40 tons per shift
( 8 hours )
5, Press box size, bale size & bale shape can be customized
Gaode has fully testing equipment to ensure productivity and quality
Gaode has achieved CE,ISO,SGS approval.
Gaode product will be tested in the factory line before packed.
Gaode product is strongerly fixed by steel wires when loading.
China famous trade mark
Thirteen years focused on Recycling Equipment.
Gaode equipment have export to more than 10 countries in Europe, the Middle East, Southeast Asia,Africa, South America and areas etc.
6months guarantee for whole machine
24hours technical support by email
Calling or door to door service
User manual and detailed video
Q1:Can I add my logo on the machines?
A: Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter.
Q2:How can i get the after-service?
A: We will send you the spare parts by free if the problems caused by us.
If it is the men-made problems,we also send the spare parts,but you should pay.
Q3:Do you have inspection procedures for machines?
A:100% self-inspection before packing
Q4:Can I have a visit to your factory before the order?
A:Sure,welcome to visit our factory.
Here is our factory address:No.691, Chengshan Road, Jiangyin City, Jiangsu Province, China.
Q5: Can we order one set machine?
A:Yes, you can.
Contact information:
Tracy
Skype: bellabest4
Sales representative
Jiangsu Gaode Hydraulic Machinery Co.,Ltd
China factory
ADD: No. 691 Chengshan Road, Jiangyin City, Jiangsu Province.
Tel: +86 15896491581(24 hours service) | Fax: +86 510 8699399
The finished products:
