low cost high capacity hydraulic heavy metal baler and shear
Applications:
The hydraulic baler & shear machinery is suitable for the cutting of scrap materials.Metal pieces are pressed 2-0r-3-dimensionally by using the pressing lid,wing and feeding pusher,and cut or broken into pieces.
Features:
1.Pre-compress and cut scrap
2.Cut bars and profiles
3.Package light scrap
4.Squeeze and cut car bodies
Technical parameter | ||||||||||
Parameter | RMKS | |||||||||
Cutting cylinder | Model | YG560/400-850 | Stroke | 850mm |
| |||||
Max thrust | 6300KN | Quantity | 1set |
| ||||||
Press cylinder | Model | YG280/200-650 | Stroke | 650mm |
| |||||
Max force | 1600KN | Quantity | 1set |
| ||||||
Side cylinder (level 1) | Model | YG180/120-500 | Stroke | 500mm |
| |||||
Max lid force | 630KN*3 | Quantity | 3sets |
| ||||||
Side cylinder (level 2) | Model | YG200/140-500 | Stroke | 500mm |
| |||||
Max force | 800KN*3 | Quantity | 3sets |
| ||||||
Discharge cylinder | Model | YG220/160-6100 | Stroke | 6100mm |
| |||||
Max force | 1000KN | Quantity | 1set |
| ||||||
Press box size (L*W*H))
| 6000*2000*1250mm |
| ||||||||
Bale size (L*W*H)
| 750*650mm |
| ||||||||
Hydraulic system working pressure | 25MPa |
| ||||||||
Power | 180KW |
| ||||||||
Power supply | 380V/3PH,50Hz |
| ||||||||
Blade length | 880mm |
| ||||||||
Capacity | 8-22tons/hour |
| ||||||||
Shear frequency | 3-5time/min |
| ||||||||
Max cutting force (tensile strength of material ≤440MPa) | Round steel Φ150mm |
| ||||||||
Billet 135*135mm | ||||||||||
Steel plate 60*600mm | ||||||||||
Motor | Model | YZ-225M-4 | Power | 45KW |
| |||||
Nominal speed | 1480rmp | Quantity | 4sets |
| ||||||
High pressure pump | Model | A7V | Nominal force | 40MPa |
| |||||
Nominal outflow | 160ml/r | Quantity | 4sets |
| ||||||
Load Cotainer
GAODE Hydraulic Machinery has been a trusted name in the waste recycling equipment industry for over a decade as a dedicated Chinese manufacturer of scrap metal recycling equipment, our flagship products includethe shear baler, scrap baler, scrap shear, and recycling crane. In addition to scrap metal processing equipment, we also supply horizontal baler and vertical baler for compacting plastic, paper, cardboard, straw, textile and more types of wastes.
Our company was first inaugurated in 2003.We have combined advanced production and testing instruments with state-of-the-art manufacturing techniques to yield outstanding product quality.
Our GAODE brand has received critical acclaim both domestically and overseas. As a trusted waste recycling equipment manufacturer, we have successfully passed the certification of both the TUV and the ISO9001 Quality Management System. We are currently in the process of obtaining the approval of European standards such as CE and UL.
Company Show
The Finished Products
Fair Show
Certification
6months guarantee for whole machine
24hours technical support by email
Calling or door to door service
User manual and detailed video
Q1:Can I add my logo on the machines?
A: Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter.
Q2:How can i get the after-service?
A: We will send you the spare parts by free if the problems caused by us.
If it is the men-made problems,we also send the spare parts,but you should pay.
Q3:Do you have inspection procedures for machines?
A:100% self-inspection before packing
Q4:Can I have a visit to your factory before the order?
A:Sure,welcome to visit our factory.
Here is our factory address:No.691, Chengshan Road, Jiangyin City, Jiangsu Province, China.
Q5: Can we order one set machine?
