Scrap Stainless Sheet Alligator Hydraulic Cutting Machine
Scrap Metal Chip
Cutting machine Q91Y is suitable for ferrous & non-ferrous metal smelting industry
to shear into acceptable pieces
Q91Y4000 technical specifications of cutting machine:
1 |
Press Box Size(L*W*H)
|
5000*2000*1300mm |
||||
2 |
Bale Size(L*W*H)
|
750*550mm |
|
|||
3 |
Hydraulic System Pressure |
25 MPa |
|
|||
4 |
Total Motor |
90 KW |
|
|||
5 |
Power |
380V/3PH,50Hz |
|
|||
6 |
Blade Length |
900mm |
|
|||
7 |
Pressing Length |
630mm |
|
|||
8 |
Shear Angular |
10 |
|
|||
9 |
Shearing Frequency (times/min) |
3 time/min |
|
|||
10 |
Capacity(Ton/Hour) |
4-12 |
|
|||
11 |
Max Cutting Force (material Tensile Strength no more than 440MPa) |
Round TeelΦ115mm |
|
|||
Billet 105*105mm | ||||||
Steel Plate 60*600mm | ||||||
12 |
Motor |
Model |
YZ-225M-4 |
Nominal Power |
45KW |
|
Nominal Speed |
1460rmp |
Quantity |
2 pieces |
|
||
13 |
Hydraulic Pump |
Model |
A7V |
Nominal Pressure |
31.5MPa |
|
Nominal Outflow |
160ml/r |
Quantity |
2 Pieces |
|
||
Certificates Of Scrap Stainless Sheet Alligator Hydraulic Cutting Machine:
Welcome to our factory
Guarantee and after-sale service
6months guarantee for whole machine
24hours technical support by email
Calling or door to door service
User manual and detailed video
