GM100 Non Destructive Ultrasonic Thickness Tester
- Shanghai Shenzhen Qingdao Ningbo
- Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | China Coal | |
| Model Number | GM100 |
Product Description
Introduction of GM100 Non Destructive Ultrasonic Thickness Tester
1. Automatic proofreading zero systematic errors can be corrected;
2. Linear automatic compensation, over the full range of the probe using computer software non-linear error correction to improve accuracy;
3. Using the arrow keys keys to the speed of sound, thickness Discovery queries and speed adjustment;
4. The coupling state TIP: Provides flag coupling by observing its apparent steady-state coupling is normal;
5. Can store ten thickness value, shut down after the data is not lost, convenience aerial and field work;
6. Measuring the Sound Velocity Function: specimen thickness directly measure its speed of sound, the look-up table or conversion to avoid the inconvenience;
7. can store 12 speed of sound values;
8. Low battery indicator;
9. Automatic shutdown: regular automatic shutdown can help you save power;
10. The key switch long life, more than 10,000 times, improve service life;
11. manually shut down: the boot state press "O" key to shutdown.
Main Parameter of GM100 Non Destructive Ultrasonic Thickness Tester
Measuring range: 1.2 to 220 mm (steel)
Accuracy: ± (1% H + 0.1) mm
Resolution: 0.1mm
Velocity range: 1000 ~ 9999m / s
Operating Frequency: 5MHz
Pipe measurement limit: Φ20 * 3mm (Steel)
Display: four-digit LCD
Measuring the speed of sound: 1000-9999m / s, the test piece thickness <when 20mm, sound velocity measurement accuracy of ± 1%;
Specimen thickness: > 20mm, sound velocity measurement accuracy of ± 5%
Operating temperature range: 0-40 degrees
Power supply: three 1.5V AAA alkaline batteries
Current job: normal test ≤50mA; open LED backlight ≤120mA;
Quiescent current :≤20uA.
Dimensions: 72x146x29mm
Product Weight: 202G
Figure Photos of GM100 Non Destructive Ultrasonic Thickness Tester
