Pure Breathing Air Compressor MCH6/ET

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Other, Other, Portable

Configuration:

Portable

Shandong China Coal Industrial & Mining Supplies Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Other, Portable

Configuration Portable

Power Source AC Power

Lubrication Style Lubricated

Mute Yes

Place of Origin Shandong, China

Model Number MCH-6

Voltage 220V/380V, 220V/380V

Dimension(L*W*H) 350*650*390mm

Weight 40kg, 40kg

Certification CE EN

Warranty life long maintenance

Specifications

Breathing Air Compressor MCH6/ET:
1) High pressure
2) Electricity saving
3) Certificate: CE
4) Low noisy

Product: Pure Breathing Air Compressor MCH6/ET

Company: Shnadong China Coal Industrial & Mining Supplies Group Co., Ltd.

Product Features

MCH 6 series low noise portable pressure air compressor is the smallest, lightest portable breathing air compressor in the whole industry.
The MCH6 series only 39 KG, can easily put it in the trunk of the car , carry to use the site.
It can be used in fire, scuba diving, shooting , emergency rescue, chemical, oil field and other fields.
Convenient to move, easy operation, and the silent high pressure air compression manufacturing meet EN 12021 international breathing compressed air standard.
The oil and contaminants in the compressed air are removed by filters and oil-moisture separators in the duration of compression,so the outlet air is pure and odorless.It is safe and reliable breathing air supply machine.

Product Structure

Optional gasoline engine, three-phase, 4-stage-phase electric drive motor
Four cylinder level 4 high-pressure compressor
Specially treated alloy cylinder and pistons
Stainless steel cooler between every level
Installed in the 400 bar high pressure on the compressor pressure gauge
1.2 meters high pressure air tube, joints according to the needs of you
High temperature resistance plastic blowing steel frame
Manual stopping device
Precision air-intake filter
High-strength Stainless steel fan cover
Two oil-water separator, two drain valve (optional automatic decontamination)
Activated carbon molecular sieve filtration system
Filter is made by seamless aluminum alloy, outer can endure 550bar pressure
Terminal safety valve pressure stepless adjustment
To set pressure automatic stop, prevent the relief valve frequent rev. Jump, ensure safety and security

MCH-6/ET STANDARD

Main Technical Parameters:

Model	MCH-6/ET STANDARD
Charging Rate	100L/Min-6m3/h-3.5CBM
Filling Time Pressure	6.8L 0-300Bar/20Min 10L 0-200Bar/20Min
Working Pressure	225Bar/3200Psi 300Bar/4700Psi
Driven By	Three-Phase Electric Motor
Power	3KW
Dimensions	Height: 35cm Width: 65cm Depth: 39cm 356539cm
Weight	39kg
Noise Pressure	83 db
No. Of Stages and Cylinders	4
Lubricating Oil Capacity	300cc (0.3L) 300ml
Lubricant	Coltri Oil CE 750 Coltri Oil CE 750
Frame	Powder Coated Steel
Oil/Moisture Separator	After Last Stage
Filtration	Filter Cartridge Activated Carbon and Molecule
Full Load Amp	11.5A(230V-50/60 HZ) 6.7A(400V-50/60 HZ
Interstage Coolers and After Coolers	Stainless Steel
Breathing Air	EN 12021 CGA E
Suction Filter	2 Micro Paper--25 Micro Polyester
