Home > Manufacturing & Processing Machinery > Mixing Equipment > Mixing Tank > PVC Mixing Plant

PVC Mixing Plant

Name: PVC Mixing Plant
Brand: Sevenstars
SKU: 141035330
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Application:

Other, PVC Powder +CaCO3+ other additive

Additional Capabilities:

Other, blending, drying, coloring

Place of Origin:

Jiangsu, China

Contact Supplier Request Quote Chat Now

Zhangjiagang Sevenstars Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Application Other, PVC Powder +CaCO3+ other additive

Additional Capabilities Other, blending, drying, coloring

Place of Origin Jiangsu, China

Brand Name Sevenstars

Model Number SRL-Z500/1000

Specifications

1.Used for drying ,colour .and mixing. PVC powder .
2.Heating mixer
3.High speed.

1	Model	/	SRL-Z500/1000 mixer group
Hot mixer
1	total volume of hot mixer	L	500
2	effective volume of hot mixer	L	375
3	material weight/batch	kg/batch	≤160
4	Output	kg/h	≤800
5	motor power	KW	55/75, double speed motor
6	Thickness of wall of barrel (stainless steel 304 )	mm	8
7	Thickness of bottom of barrel (stainless steel 304 )	mm	10
8	hot mixer rotating speed	r/min	430-860
9	Quantity of stirring blade	pcs	3(1Cr18Ni9Ti)
10	mixing time	min/batch	8-10
11	Heating method	Electric heating and self-mixing heating

cooling mixer
1	cooling mixer volume	L	1000
2	effective volume of cooling mixer	L	640
3	motor power	KW	18.5
4	material of cooling mixer blade	/	ZG1Cr18Ni9Ti
5	stirring blade rotating speed	r/m	60
6	Thickness of wall of barrel (stainless steel 304 )	mm	8
7	Thickness of bottom of barrel (stainless steel 304 )	mm	10
8	lift control method	/	pneumatic
9	Cooling method	/	water cooling
10	cooling time	min/batch	10-15
11	Total weigth of the overall machine	kg	5800

We provide different capacity for you. You are always welcome no matter when you need any information.
product keyword:PVC mixing Plant , pvc compounding plant, dry powder mixing plant
