Help CenterMulti-function Shredding Machine/equipment
Related Products
-
WT Serial Waste Plastic Single Axle/shaft Shredder MachineUS$ 10,000 - 30,000MOQ: 1 Set -
Plastic Recycling Shredder/crusher/grinder MachineUS$ 15,000 - 30,000MOQ: 1 Set
-
Waste Plastic Recycling Shredder Machine(scrap Metal Shredder)US$ 15,000 - 30,000MOQ: 1 Set
-
Single Plastic/paper Shredder/grinder MachineUS$ 50,000 - 150,000MOQ: 1 Set
-
Two Shaft Wood Pallet ShredderUS$ 12,500 - 35,000MOQ: 1 Set
Specifications
1.single shaft shredder2.easy operation
3.high efficiency and low noise
4.long working life and good price
Single shaft plastic shredder character:
1. This machine is suitable to treat the big size of plastic product,
Such as big diameter plastic pipe, pressing plastic film and others.
2. The blade base and blade on the rotary roller can be disassembly.
It is easy to clean and maintance.
3. The rotary blade adopt the V design, It can decrease the noise
And decrease energy consumption.
4. Each rotary blade with 4 cutting knife edge, when the rotary
Blade is wear, it can be rotated to 90 degree, then the blade can continues use.
5. Each fixed blade with 2 cutting knife edge, when the fixed blade is
Wear, it can be rotated to 180 degree, then the blade can continues use.
6. The main axis is drive by gearbox, its running very stably, low noise and strong power.
7. The material push feeding system is hydraulic ways, its running very stably.
The machine is controlled by PLC system, the blade can rotated in opposite
Direction, and also can close automatic if something unexpected happen,
With very high safety service.
Special thick, thoughness, large-scale material
Big head material, large plastic pipes, packing barrels, forklift pallets,
Wood, puching bags, fishing nets, plastic sheeting, tires, etc.
| Model | Shaft Dia(mm) | Shaft width(mm) | Output(KG/H) | Dimension(L×W×H)mm |
| PC-600 | 250mm | 600mm | 200-300 | 1750×1250×1680 |
| PC-800 | 250mm | 800mm | 300-500 | 1820×1400×1740 |
| PC-1000 | 250mm | 1000mm | 600-800 | 2650×1550×2000 |
| PC-1200 | 400mm | 1200 | 800-1000 | 3000×2100×2300 |
