plastic recycling granulator price

Specifications

plastic recycling granulator
1.High output:200-1000kg/h
2.CE & ISO
3.Low consumption
4.Suitable for PP PE film

plastic recycling granulator price



Feature and Function:

Water ring type pelletizing line,recycling PP PE film bags,make them into pellets.



Process flow:

Conveyor→ PE film compactor→ Extruding system→ Die-head and High speed Net exchanging system→ water ring or noodle type pelletizing machine→ dewatering machine→ vibrating sieve→ Air Blower → Storage hopper



Detailed description of plastic recycling granulator price



1. Conveyor:convey PP PE film or flakes into compactor.

2. PE film compactor:crushing and compress film,and feed compressed film into extruder forcedly,to make the the production capacity high and stable.

3.Extruding system:plasticizing material and exhausting gas.

4.High speed Net exchanging system and Die-head:filter material impurity,to make production more stable.

5.water ring pelletizing machine:cutting pellets in water.

6.Water tank:cooling pellets.

7.Dewater machine:make pellets dry.

8.Vibration sieve:remove bad pellet and keep good pellet.

9.Air Blower:convey good pellets into silo.

10:Storage silo:keep pellet.







Technical data:



Extruder	SJ90	SJ120	SJ150	SJ180
Main Motor Power	55KW	75kw	110kw	185kw
Production capacity	150KG/H	150-250kg/h	300-400kg/h	450-800kg/h
