Good Quality PP PE Plastic Granules Making Machine / PP Film Granulating Machine

No.

Machinery

Usage

1

belt conveyor

feed the clean films or bags into the cutting compactor

2

Metal detector

check whether there is metal in the films or bags, protect the blades of cutting compact and screws

3

Cutting compactor

cut the materials again and make materials shrink, then force feed the shrunk material into the extruder. for the same capacity, the power consumption is only 50% of the agglomerator.

4

Single screw extruder

for plasticizing the materials and exhausting the gas, it is made of 38CrMoAlA generally.

5

hydraulic screen changer

filter the impurities, improve the granules quality

6

Pelletizer

includes mould and pelleting blades, we can provide both vertical type and horizontal type

7

Water cooling tank:

use circular water for cooling the granules immediately after pelleting cut

8

Vertical dewatering machine

convey the granules helically from bottom to top, the rotary rotor and the stainless screen help to drain the water, and convey the granules out from the machine

9

Blower system

use the blower to blow the granules to the storage silo through the SS304 pipe

10

Storage silo

for storing the final films

11

Control system

use SUZHOU SIEMENS and China famous electrical parts
