Film Granulation Line

Specifications

Film Granulation Line

Project evaluation

According to our communications for your film recycling business, we’d like to recommend our standard SJ-150 strand granulation line. This granulation line is composed of belt conveyor, force feeder, SJ-150 single-screw extruder and downstream assistant machines. Please check the below information:

1.1 Material characteristics

The material to be treated: PE/PP films.

Finished product: PE/PP granules

Capacity: 200~250kg/hr

1.2 Basic Infrastructure (Provided by customer)

a. Space for film granulation line in workshop:

20m (length)×3.5m(width)×3.5m(height) (Adjustable according to your factory structure).

b. Electricity network: 380V/50Hz (Adjustable according to your local voltage standard)

c. Wire/cables: wires/cables from customer’s general control cabinet to the main control cabinet for film granulation line; all electrical cable from the main control cabinet to each machine.

d. Water supply: main water pipeline supply and water pipes to machines

e. Means for lifting the machines when unloading and positioning

f. Everything else not clearly mentioned above

1.3 Energy consumption:

a. Electricity requirement

Total power installed: 267Kw, actual power consumption percentage: 80%

b. Water requirement: all water can be recycled

c. Manpower requirement: 2 persons
